IBM System x3550 M4 User Manual

Table 1. Features and specifications (continued)
Attention:
v Design to ASHRAE Class A3, ambient
of 40°C, with relaxed support:
– Support cloud like workload with no
performance degradation acceptable
(Turbo-Off)
– Under no circumstance, can any
combination of worst case workload
and configuration result in system
shutdown or design exposure at
40°C
v Specific microprocessors supported
environment:
– Microprocessor Intel Xeon E5-2690,
135W:
- Temperature: 10°C to 27°C
(41.0°F to 80.6°F)
- Altitude: 0 to 304.8 m (1,000 ft)
– Microprocessor models with 115W
and 130W:
- Temperature: 10°C to 35°C (50°F
to 95°F)
- Altitude: 0 to 914.4 m (3,000 ft)
Integrated functions:
v Integrated Management Module II
(IMM2), which consolidates multiple
management functions in a single chip.
v Intel I350AM4 Quad Port Gigabit
Ethernet controller with Wake on LAN
support
v Eight Universal Serial Bus (USB) ports
for 3.5-inch models. Seven Universal
Serial Bus (USB) ports for 2.5-inch
models. One port is for optional USB
flash device with embedded hypervisor
software is installed.
v Six network ports (four 1 Gb Ethernet
ports on the system board and two
additional ports when the optional IBM
Dual-Port 10 Gb Network Adapter is
installed)
v One System Management 1 Gb
Ethernet port on the rear connected to a
systems management network. This
system management connector is
dedicated to the IMM2 functions.
v One serial port
RAID controllers (depending on the
model):
v A ServeRAID H1110 SAS/SATA
adapter that provides RAID 0, 1, and
10.
v A ServeRAID M1115 SAS/SATA
adapter that provides RAID 0, 1, and
10 with optional FoD RAID 5/50 and
SED (Self Encrypting Drive) upgrade.
v A ServeRAID M5110 SAS/SATA
adapter that provides RAID 0, 1, and
10.
Optional upgrade:
– RAID 5/50 (512 MB Cache) with
optional FoD RAID 6/60 and SED
upgrade
– RAID 5/50 (512 MB Flash) with
optional FoD RAID 6/60 and SED
upgrade
– RAID 5/50 (1 GB Flash) with
optional FoD RAID 6/60 and SED
upgrade
– RAID 5/50 and SED (Zero Cache)
v A ServeRAID M5120 SAS/SATA
adapter that provides RAID 0, 1, and
10.
Optional upgrade:
– RAID 5/50 (512 MB Cache) with
optional FoD RAID 6/60 and SED
upgrade
– RAID 5/50 (512 MB Flash) with
optional FoD RAID 6/60 and SED
upgrade
– RAID 5/50 (1 GB Flash) with
optional FoD RAID 6/60 and SED
upgrade
– RAID 5/50 and SED (Zero Cache)
Size:
v 1U
v Height: 43 mm (1.7 inches)
v Depth: 734 mm (28.9 inches)
v Width: 429 mm (16.9 inches)
v Weight: approximately 16.4 kg (36.16
lb) when fully configured
Heat output:
Approximate heat output:
v Minimum configuration: 461 Btu per
hour (AC 135 watts)
v Maximum configuration: 2900 Btu per
hour (AC 850 watts)
Acoustical noise emissions:
v Sound power, idling: 6.2 bels maximum
v Sound power, operating: 6.5 bels
maximum
Electrical input:
v Sine-wave input (50 - 60 Hz) required
v Input voltage low range:
– Minimum: 100 V ac
– Maximum: 127 V ac
v Input voltage high range:
– Minimum: 200 V ac
– Maximum: 240 V ac
v Input kilovolt-amperes (kVA),
approximately:
– Minimum: 0.14 kVA
– Maximum: 0.90 kVA
Notes:
1. Power consumption and heat output
vary depending on the number and type
of optional features installed and the
power-management optional features in
use.
2. The noise emission level stated is the
declared (upper limit) sound power
level, in bels, for a random sample of
machines. All measurements are made
in accordance with ISO 7779 and
reported in conformance with ISO 9296.
Chapter 1. The System x3550 M4 server
7
