The Ultrabay release lever pops out (7) when the bay
slot is slightly lifted as in step 6.
6
7
a
When installing: After inserting the Ultrabay release lever
into the rectangular hole of base cover,
slide the Ultrabay latch knob toward you
until it snaps (a). Then attach the bay
to the computer.
Detach the bay slot to the direction of arrow 9, to avoid
damaging the Ultrabay release lever 8.
9
8
Removing and replacing a FRU
ThinkPad A30, A30p 97
