IBM ThinkPad A30 - Page 114

8
9
9
When installing: Make sure that both of the connectors
are firmly attached.
10
When installing: Attach the system board so that the two
small projections on the base cover fit
into the holes provided.
(continued)
Removing and replacing a FRU
108 ThinkPad A30, A30p (MT 2652/2653/2654)
