Installing a Memory Option
c) Press on the shaded area 1 until the DIMM adapter
snaps into the memory slot connector.
Press on three points (both sides and center) of the shaded
area.
1
d) Make sure the DIMM adapter is firmly connected.
12
Align the matching ( ) marks on the memory slot cover and
the bottom of the computer; then slide in the memory slot
cover.
1
2
Chapter 6. Installing and Removing Options 129
To Next Page
