IBM ThinkPad T40 series Hardware Maintenance Manual

Feature Description
Display v 14.1-inch, 16M colors, XGA (1024 × 768
resolution) TFT color LCD
v 14.1-inch, 16M colors, SXGA+ (1400 ×
1050 resolution) TFT color LCD
Standard memory T40, T40p series:
v 256 MB DDR SDRAM SO-DIMM
(PC2100) card × 1
v 512 MB DDR SDRAM SO-DIMM
(PC2100) card × 1
v 1 GB DDR SDRAM SO-DIMM (PC2100)
card × 1
T41 series:
v 256 MB DDR SDRAM SO-DIMM
(PC2700) card × 1
v 512 MB DDR SDRAM SO-DIMM
(PC2700) card × 1
v 1 GB DDR SDRAM SO-DIMM (PC2700)
card × 1
Optional memory T40, T40p series:
v 128 MB DDR SDRAM SO-DIMM
(PC2100) card
v 256 MB DDR SDRAM SO-DIMM
(PC2100) card
v 512 MB DDR SDRAM SO-DIMM
(PC2100)
v 1 GB DDR SDRAM SO-DIMM (PC2100)
T41 series:
v 128 MB DDR SDRAM SO-DIMM
(PC2700) card × 1
v 256 MB DDR SDRAM SO-DIMM
(PC2700) card × 1
v 512 MB DDR SDRAM SO-DIMM
(PC2700) card × 1
v 1 GB DDR SDRAM SO-DIMM (PC2700)
card × 1
(maximum of 2048 MB)
CMOS RAM v 242 bytes
Hard disk drive v 20.0 GB, 4200 rpm, 2.5-inch, IDE
interface (supported by CTO in T40
series)
v 30.0 GB, 4200 rpm, 2.5-inch, IDE
interface
v 40.0 GB, 5400 rpm, 2.5-inch, IDE
interface
v 60.0 GB, 7200 rpm, 2.5-inch, IDE
interface
v 80.0 GB, 4200 rpm, 2.5-inch, IDE
interface (option in T41 series)
(continued)
Product overview
46 MT 2373/2374/2375/2376/2378/2379

IBM ThinkPad T40 series Specifications

General

Processor	Intel Pentium M (1.3 GHz - 1.7 GHz)
Chipset	Intel 855PM
Hard Drive Interface	ATA-100
Modem	56K V.92
Release Year	2003
RAM	256 MB - 2 GB (DDR SDRAM)
Storage	30 GB - 80 GB (HDD)
Display	14.1"
Graphics	ATI Mobility Radeon 7500 or 9000
Optical Drive	DVD-ROM/CD-RW Combo
Operating System	Windows XP Professional
Weight	2.2 kg (4.9 lbs)
Battery	Li-Ion
Wireless	Intel PRO/Wireless 2100
Ethernet	10/100 Mbps
Ports	2 x USB 2.0, VGA, RJ-11, RJ-45, Audio In/Out
Dimensions	311 mm x 255 mm x 26.6 mm (12.24" x 10.04" x 1.05")
