IBM ThinkPad T40 series Hardware Maintenance Manual

Feature Description
Ultrabay Slim device
(standard)
v DVD drive, 9.5 mm high
v DVD/CD-RW combo drive, 9.5 mm high
I/O port v External monitor connector
v Stereo headphone jack
v Monaural microphone jack
v Infrared port
v Parallel connector
v Docking connector
v RJ11 connector
v RJ45 connector
v TV-out connector (S-Video)
v Universal serial bus (USB) connector ×
2 (compatible with USB 1.1 and 2.0)
Internal modem v 56.6 Kbps
Audio v Built-in stereo speakers
v Software control volume
Infrared transfer v IrDA 1.1
Mini PCI adapter T40, T40p series:
v IBM Dual-Band 11a/b Wi-Fi Wireless
Mini PCI Adapter
v Cisco Aironet Wireless 802.11b
v Intel
®
PRO/Wireless LAN 2100 3B Mini
PCI Adapter
T41 series:
v Cisco Aironet Wireless 802.11b
v Intel
®
PRO/Wireless LAN 2100 3B Mini
PCI Adapter
v IBM 11a/b/g Wireless LAN Mini PCI
Adapter
PC Card v One Type-III
v Two Type-II
Ethernet (on the
system board)
T40, T40p series:
v 10/100Base Ethernet
v Gigabit Ethernet
T41 series:
v Gigabit Ethernet
Communication
daughter card
(CDC)
v V.90 modem daughter card (MDC)
v IBM Integrated Bluetooth with 56K
Modem (BMDC)
Touch pad v UltraNav
ThinkLight Yes
Battery v Li-ion battery (6 cells)
v Li-ion battery (9 cells)
v Ultrabay Slim Li Polymer battery (option)
AC adapter v 72-watt type
Preinstalled
operating system
v Windows XP Professional
v Windows 2000
Product overview
ThinkPad T40, T40p, T41 Series 47

IBM ThinkPad T40 series Specifications

General

Processor	Intel Pentium M (1.3 GHz - 1.7 GHz)
Chipset	Intel 855PM
Hard Drive Interface	ATA-100
Modem	56K V.92
Release Year	2003
RAM	256 MB - 2 GB (DDR SDRAM)
Storage	30 GB - 80 GB (HDD)
Display	14.1"
Graphics	ATI Mobility Radeon 7500 or 9000
Optical Drive	DVD-ROM/CD-RW Combo
Operating System	Windows XP Professional
Weight	2.2 kg (4.9 lbs)
Battery	Li-Ion
Wireless	Intel PRO/Wireless 2100
Ethernet	10/100 Mbps
Ports	2 x USB 2.0, VGA, RJ-11, RJ-45, Audio In/Out
Dimensions	311 mm x 255 mm x 26.6 mm (12.24" x 10.04" x 1.05")
