3
2
2
Antenna cables 4a and 4b in the following illustration
are for the wireless LAN feature, and 5 is for the modem
feature.
Note: When unplugging the antenna jack, do not pull the
cable; it might snap. Unplug the jack by pulling a
tab with your fingers.
5
4a
4b
Removing and replacing a FRU
82 ThinkPad X30, X31 (MT 2672/2673)
