21 Adjustment and Calibration
Adjustment of customer specific temperature coefficient "USER TC"
Pressing the navigation key while adjusting the temperature coefficient to "USER TC" the
HDM97Pocket enters a second dialog to adjust the value itself instead of directly going back to measuring
mode.
→ USER TC
→ enters the dialog to adjust the user temperature coefficient set
→ cancel and discard setting
Display: EDIT TC1
37.00 °C Temperature associated with the coefficient
2.071 %/K (Example 2.070, navigation key has been pressed once)
Keys: → increments current value
→ decrements current value
→ Applies the value and leads to the adjustment dialog for the second
pair
→ Discard adjustment and goes on using the last active temperature
coefficient setting
Display: EDIT TC2
25.00 °C Temperature associated with the coefficient
2.001 %/K (Example 2.000, navigation key has been pressed once)
Keys: → increments current value
→ decrements current value
→ Applies the coefficient set. The displays shows "ADJ OK" for 2
seconds
→ Discard adjustment and goes on using the last active temperature
coefficient setting
