iC-TW29 26-BIT ENCODER PROCESSOR
WITH INTERPOLATION AND BiSS INTERFACE
Rev C1, Page 8/28
ABSOLUTE MAXIMUM RATINGS
These ratings do not imply operating conditions; functional operation is not guaranteed. Beyond these values damage may occur.
Item Symbol Parameter Conditions Unit
No. Min. Max.
G001 VDD Voltage at DVDD, AVDD, and IOVDD Referenced to DVSS, AVSS, and IOVSS
respectively
–0.3 4.1 V
G002 Vpin Pin Voltage at any pin Referenced to DVSS, AVSS, and IOVSS –0.3 AVDD +
0.3
V
G003 Ipin Input Current into any pin –2 2 mA
G004 Vesd1 ESD Susceptibility HBM, 100 pF discharged through 1.5 kΩ 4 kV
G005 Tj Junction Temperature –40 150 °C
THERMAL DATA
Item Symbol Parameter Conditions Unit
No. Min. Typ. Max.
T01 Ta
Operating Ambient Temperature Range
–40 125 °C
T02 Rthja Thermal Resistance Chip to Ambient QFN32-5x5 surface mounted to PCB
according to JEDEC 51
40 K/W
T03 Ts Storage Temperature –40 150 °C
All voltages are referenced to pin AVSS unless otherwise stated.
All currents owing into the device pins are positive; all currents owing out of the device pins are negative.
