DX8
Dual Balance Charger/Discharger/DC Power
LiPo/LiIo/LiFe/LiHV/LTO/NiZn /User Setup
After adding a program, it will switch to LiPo/LiIo/LiFe/LiHV/LTO/NiZn/User battery in Type option on the MEMORY
SETUP interface, and set the number of cells and capacity, if there is no setting for the number of cells, the charger will set
Auto by default. After editing all parameters for the program, click "Save" to save and return to the previous interface.
As shown in the above picture, there are Charge, Storage, Discharge, Cycle and Balance Only for
LiPo/LiIo/LiFe/LiHV/LTO/User., while Charger, Discharge and Cycle for Nizn user only.
LiPo/LiIo/LiFe/LiHV/LTO/NiZn/User Charge Setup
Select Program→Charge to enter Charge setup interface.
1. When the value of charge cells voltage exceeds the recommended value (LiPo 4.2V, LiIo 4.1V, LiFe 3.6V, LTO
2.85V), the charger will display a warning and alarm. As long as the user changes the values, the battery types and cells
voltage value on the main charging interface will be displayed alternately.
2. For the setting process for all program in this manual, tick Show to display the setting program on MEMORY
SETUP (shown in the following picture), and vice versa; the built-in memory is ticked by default.
LiPo/LiIo/LiFe/LiHV/LTO/NiZn/User NON-Balance Charge Setup
When switch to Not Balance on Chg Mode, only Chg End Current is available for charging end condition, and “Set …”
behind Chg Mode and Chg End Current are inactive.
Chg Current: 0.05A-30A; default: 2A
Chg Mode: Slow Balance, Normal Balance( default),
Fast Balance, User Balance, Not Balance
Chg End Current: 1%-50%; default: 10%
Chg Cell Volt:
LiPo 3.85V/Cell-4.35V/Cell
；
default
：
4.2V/Cell
LiIo 3.75V/Cell-4.35V/Cell
；
default
：
4.1V/Cell
LiFe 3.30V/Cell-3.80V/Cell
；
default
：
3.6V/Cell
LiHV 3.90V/Cell-4.40V/Cell
；
default
：
4.35V/Cell
LTO 2.50V/Cell-3.10V/Cell
；
default
：
2.85V/Cell
NiZn 1.20V/Cell-2.00V/Cell
；
default
：
1.90V/Cell
User 1.00V/Cell-4.80V/Cell
；
default
：
1.00V/Cell
Cells：Auto(default), 1-8S
Capacity：Ignore(default),50-999900mAh
