12
The SC3006 is a programmable, auto changeover, single stage heat, single stage cool thermostat. It
functions with air conditioning, heat pumps, gas, oil or electric heat systems.
The thermostat activates the heating appliance when the room temperature is below the set heat
temperature (by the differential temperature) and the red indicator light on the thermostat will light. The
SC3006 will stop outputting and the red light will turn off when the call for heat has been satisfied. With
heat pumps, the thermostat will not let the compressor come on for 4 minutes after it turns off. This
protects your compressor.
When the room temperature is greater than the set cool temperature (by the differential temperature),
the cooling device is activated and the green indicator light on the thermostat will turn on. The SC3006 will
stop outputting and the green light will turn off when the call for cooling is satisfied. The thermostat will
not let the compressor come on for 4 minutes after it turns off. This protects your compressor.
The SC3006 has five possible operating modes: OFF, Heat, Cool, Heat & Cool and Program mode. In off
mode, the thermostat will not turn on heating or cooling devices. The manual fan can be turned on in all
operating modes using the fan switch. In heat mode, the thermostat controls the heating system. In the
Cool mode, the thermostat controls the cooling system. In heat & cool mode, the thermostat controls
both the heating and cooling systems. In program mode, the thermostat will automatically be controlled by
the set program. Program mode can function with heat mode, cool mode or heat & cool mode. The clock
display alternates with the set temperature display for heat & cool mode.
The program schedule can be overridden by changing the set temperature ( or button). This puts the
SC3006 thermostat into a 2 hour temporary hold. After 2 hours, it will automatically return to the program
schedule.
The SC3006 also has a button lockout feature. This enables the thermostat to be set to the proper mode
and temperature and locked so it cannot be tampered with.
Mode of Operation
