10
CAUTION!
:
Do not use air conditioning when the outdoor temperature is below 50 degrees. This
can damage your air conditioning system and cause personal injuries.
Note:
First button press activates backlight only.
1. Move the Fan Auto/On switch to the Auto position.
2. Press the button to enter desired operating mode.
Mode
8. Room temperature offset (+9°F to - 9°F) (+5°C to -5°C).
Adjust to calibrate displayed room temperature to match actual room temperature.
Press the button to advance to the next screen.
9. Maximum compressor cycles allowed per hour (d, 2-6).
– – = as many as needed, 2-6 = maximum cycles/hour
Press the button to advance to the next screen.
Configuration Mode Settings (continued)
ON
10. Status indicator light (ON, OFF).
Press the or button to select.
To exit configuration mode, press the button for 6 seconds.
Starting the Thermostat
Fan
To Next Page
