Icom IC-208H - I Optional Microphones (HM-118 N;TN;TAN)

10
1
PANEL DESCRIPTION
1
■ Optional Microphones
(HM-118N/TN/TAN)
qPTT SWITCH
Push and hold to transmit; release to receive.
wUP/DOWN SWITCHES [UP]/[DN]
➥ Push either switch to change operating frequency,
memory channel, set mode setting, etc.
(pgs. 12, 26, 56)
➥ Push either switch for 1 sec. to start scanning. (p. 41)
eUP/DN LOCK SWITCH
Slide to toggle [UP]/[DN] switches function ON and OFF.
rKEYPAD (HM-118TN/TAN only)
While pushing [PTT], push the desired key to send the
DTMF code.
w
q
ON
OFF
e
w
r
q
ON
OFF
e
• HM-118N
• HM-118TN/TAN
(DTMF)
