67
11 OTHER FUNCTIONS
■ Microphone keys
The supplied HM-133’s (optional for some versions) [F-1] and
[F-2] keys memorize the transceiver conditions.
The [UP]/[DN] keys of the standard or an optional microphone
(other than the HM-133) can be assigned functions like the
function keys on the transceiver’s front panel.
DD
[UP]/[DN] keys on a microphones
(other than HM-133)
The following functions are assigned to [UP]/[DN] keys on the
other microphones (HM-118N/TAN, etc.) when first applying
power.
• Default setting
[UP] : channel up; push and hold to start scan, push again
to stop scan.
[DN] : channel down; push and hold to start scan, push
again to stop scan.
➥ Assigning a function
q Turn the power OFF.
w While pushing the desired switch on the transceiver and
one of either [UP]/[DN] keys on the microphone, turn the
power ON.
• The function is programmed into the key.
➥ Clearing an assignment
q Turn the power OFF.
w While pushing the desired [UP] or [DN] key on the micro-
phone, turn the power ON.
DD
[F-1]/[F-2] keys on HM-133
The following conditions can be memorized into [F-1] and [F-
2] keys, independently.
• Operating frequency
• Repeater setting
(offset direction and frequency, tone ON/OFF
and frequency)
• Tone/DTCS squelch (ON/OFF, frequency/code and polarity)
• Transmit output power selection
• Tuning step
• Operating mode selection (FM/AM)
➥ Programming the band condition
Push [F-1]/[F-2] for 1 sec.
• 3 beeps sound.
➥ Recalling the band condition
Push [F-1]/[F-2] momentarily.
➥ Initializing the band condition
Push [FUNC] then push [F-1]/[F-2].
The following conditions are initialized.
• Operating band: 145 MHz band
• Repeater setting (tone frequency: 88.5 Hz, offset
frequency: 600 kHz)
•
Tone/DTCS squelch (ON/OFF: OFF, tone fre-
quency:88.5 Hz, DTCS code: 023 and polarity: NN)
• Transmit output power selection: HIGH
• Tuning step: 5 kHz
• Call channel: 1 CH, memory channel: 1CH
• Operating mode selection: FM
