8
Section 4
SCAN
Scan types
The transceiver has 4 scan types, a Tag function and 4
Resume options, for scanning versatility.
Tagged channels are independently set for Open,
Group and Priority scans. All channels may be preset
as tagged channels for all scans.
Repeatedly checks the preset Priority
channel after scanning 5 tagged channels.
Priority
channel
GROUP and PRIORITY SCAN
ch 01
ch 02 ch 03 ch 04
ch 05
ch 10
ch 09 ch 08 ch 07
ch 06
★★
★★
★★
★★
Repeatedly scans all tagged channels in sequence.
ch 40
ch 01 ch 02 ch 03
ch 04
ch 05
ch 06ch 39
OPEN SCAN
★★
★★
Ch 02
Ch 02Ch 01
Scan cancel
Ch 48
Ch 01
Ch 03Ch 04
Ch 48
★★
★★
REPEATER SCAN
Scans all repeater channels (01 to 08 and 41 to 48)* in
sequence. If there are no busy channels after scanning
channels 01 to 08 and 41 to 48,* the scan begins from 01
again, and then the transceiver transmits a signal to
search for a repeater while scanning.
* Excludes emergency repeater 05.
The IC-41PRO scans all tagged channels when a scan is
activated. When it detects a busy channel, the scan can
be set to pause, or to resume after a pause. (Except for
a Repeater scan).
• See page 6 for details on the Scan Restart function.
D Selecting a scan type
Push several times to select the desired scan type.
• Select Open, Group or Priority scan.
Push
Push
Open scan is selected.
Group scan is selected.
Priority scan is selected.
Push
Displayed
Displayed
Displayed
Scanning preparation
D Setting a Tag channel
Before setting tag channels, you must select the desired
scan type, as described above.
NOTE: All channels for each scan type are tagged by
default. To select the channels to scan, you must first
untag the undesired channels.
q Select the desired scan type.
w Rotate [ROTARY SELECTOR] to select the undesired
channel.
e Hold down for 2 seconds to untag the selected
channel.
• “S disappears when the tag setting is OFF.
Displayed
Disappears
r Repeat steps q to e until all the undesired channels
are untagged.
To tag
q Rotate [ROTARY SELECTOR] to select an untagged
channel.
w Hold down for 2 seconds to tag the selected
channel.
• “S is displayed when the selected channel is tagged.
