5 - 6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
L2035 6200002041 S.COL NLV25T-101J B 59.8/18.4
L2036 6200002041 S.COL NLV25T-101J B 64.1/3.8
L2037 6200002041 S.COL NLV25T-101J B 88.3/3.7
L2041 6180003610 S.COL 7E10L-101M 100U B 62.6/86.9
L2042 6200002861 S.COL NLV25T-4R7J B 62.9/79.3
L2053 6200002041 S.COL NLV25T-101J B 28.7/90.9
L2151 6200002041 S.COL NLV25T-101J B 36.9/121
L2152 6200002041 S.COL NLV25T-101J B 52.3/14.7
L2201 6200005011 S.COL NLV25T-100J T 27.2/126
L2202 6200005011 S.COL NLV25T-100J T 16.5/124.3
L2231 6200002041 S.COL NLV25T-101J T 34/104.2
L2256 6200002041 S.COL NLV25T-101J T 15/103.4
L2257 6200002041 S.COL NLV25T-101J T 10.5/89.7
L2260 6200002041 S.COL NLV25T-101J T 68.5/110.9
L2263 6200002041 S.COL NLV25T-101J T 62.3/99.4
L2264 6200002041 S.COL NLV25T-101J T 62.3/96.9
L2265 6200002041 S.COL NLV25T-101J T 62.4/94.3
L2266 6200002041 S.COL NLV25T-101J T 62.4/91.5
L2267 6200002041 S.COL NLV25T-101J T 66/89.6
L2268 6200002041 S.COL NLV25T-101J T 62.4/87.1
L2272 6200002041 S.COL NLV25T-101J T 71.1/90.2
L2402 6200002041 S.COL NLV25T-101J B 89.4/98
L2403 6200002041 S.COL NLV25T-101J B 89.2/84
L2404 6200002041 S.COL NLV25T-101J T 81.6/96.8
L2405 6200002041 S.COL NLV25T-101J B 89.3/95.5
L2406 6200002041 S.COL NLV25T-101J T 84.8/93.7
L2408 6200011300 S.COL EXCML16A 270U T 82.1/92.3
L2409 6200002041 S.COL NLV25T-101J B 89.3/88.5
L2411 6200011300 S.COL EXCML16A 270U T 85.1/89.7
L2601 6200009330 S.COL SLF12555T-681MR43 T 87.5/119.6
L2605 6200009330 S.COL SLF12555T-681MR43 T 71/119.6
R1 7030011400 S.RES ERJ2GE 5R6 X (5.6
Ω
) T 80.1/17
R2 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) T 80.1/17.9
R3 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) T 80.1/16.1
R5 7030011400 S.RES ERJ2GE 5R6 X (5.6
Ω
) T 74.1/17.4
R6 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) T 75.2/16.4
R7 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) T 73.4/16.4
R8 7030009200 S.RES ERJ2GEJ 390 X (39
Ω
) T 72.7/19.2
R9 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 69.9/13.3
R10 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 72.5/17.4
R11 7030005300 S.RES ERJ2GEJ 150 X (15
Ω
) T 62.1/15.9
R12 7030010040 S.RES ERJ2GEJ-JPW T 63.7/13.8
R13 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 66.6/20.6
R15 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 68.8/10.6
R16 7030003860 S.RES ERJ3GE JPW V T 62.4/12.3
R17 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 76.8/15.8
R18 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) T 44.2/17.2
R19 7030003860 S.RES ERJ3GE JPW V T 50.4/14.6
R20 7030009530 S.RES ERJ2GEJ 270 X (27
Ω
) T 69.5/19.7
R21 7030009530 S.RES ERJ2GEJ 270 X (27
Ω
) T 66.1/22.8
R22 7030010040 S.RES ERJ2GEJ-JPW T 78.1/13.8
R23 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 79.8/13.8
R24 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) T 78.1/12.9
R25 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 79.6/17.8
R27 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 81.3/8.5
R29 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 73.1/12.3
R30 7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) T 46.4/15.4
R31 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) T 42.6/17.2
R32 7030009200 S.RES ERJ2GEJ 390 X (39
Ω
) T 44.1/18.2
R33 7030010040 S.RES ERJ2GEJ-JPW T 60/18
R34 7030010040 S.RES ERJ2GEJ-JPW T 62/18
R35 7030003860 S.RES ERJ3GE JPW V T 64/18
R101 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 13.2/16
R102 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 11.9/14.6
R103 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 10.3/14.6
R104 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 15.7/13.4
R105 7030005580 S.RES ERJ2GEJ 560 X (56
Ω
) T 15.7/22.3
R106 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 13.2/20.5
R107 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 10.8/22.1
R108 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 10.8/23
R111 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 10.8/21.2
R112 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 25.6/12.5
R113 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 26.7/5.7
R114 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) B 33.1/23.4
R115 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) B 34.1/22.2
R116 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 22.3/21.3
R117 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 20.7/21.3
R118 7030009280 S.RES ERJ2GEJ 391 X(390
Ω
) B 40.9/23.2
R119 7030009280 S.RES ERJ2GEJ 391 X(390
Ω
) B 40.9/22.3
R120 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 50.3/23.5
R121 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 44/22.2
R122 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 7.8/20.3
R123 7030009280 S.RES ERJ2GEJ 391 X(390
Ω
) T 7.8/19.4
R125 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 35.5/20.2
R126 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 26.7/4.8
R127 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 25/4.8
R128 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 35.5/19.3
R202 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 18.1/31.2
R203 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 42.9/59.9
R204 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 42.9/54.3
R205 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 19.4/54.2
R206 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 42.9/51.4
R207 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 42.9/50.5
R208 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 46.4/45
R216 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 44.2/43.3
R217 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 18.1/30.3
R218 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 21.9/29.9
R225 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 19.1/29.1
R226 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 17.6/54.2
R227 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 30.9/30.9
R228 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 30.9/29.1
R301 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 44.5/28.8
R302 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 38.6/27.8
R303 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 52.5/38.9
R304 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 55.1/35.6
R305 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 59.9/33.8
R306 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 55.3/28.7
R307 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 56.7/35.6
R308 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 59.2/30.1
R309 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 58.5/29.1
R310 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 50.1/31.7
R311 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 65.3/31.3
R312 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 63.7/31.3
R314 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 73.3/32.5
R315 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 74.8/33.8
R401 7030010040 S.RES ERJ2GEJ-JPW T 75/29.7
R402 7030010040 S.RES ERJ2GEJ-JPW T 75/27
R403 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 76.7/29.7
R404 7030010040 S.RES ERJ2GEJ-JPW T 73.1/23.5
R405 7030010040 S.RES ERJ2GEJ-JPW T 85/24.1
R406 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 73.1/30.6
R407 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 73.1/25.3
R411 7030007260 S.RES ERJ2GEJ 330 X (33
Ω
) T 80/29.5
R412 7030007260 S.RES ERJ2GEJ 330 X (33
Ω
) T 80/26.8
R414 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 78.3/29.6
R416 7030010090 S.RES ERJ2GEJ 180 X (18
Ω
) T 87.8/24
R417 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 87.8/24.9
R418 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 87.8/22.9
R421 7030010090 S.RES ERJ2GEJ 180 X (18
Ω
) B 88.5/20.2
R422 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 90.1/20.2
R423 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 90.1/19.3
R424 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 88.5/21.6
R501 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 91.3/35.6
R502 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 92.9/33.8
R509 7030005580 S.RES ERJ2GEJ 560 X (56
Ω
) T 83.4/33.1
R510 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) T 83.4/34.1
R512 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 81.7/34.1
R517 7030010040 S.RES ERJ2GEJ-JPW B 80/31
R518 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 79.3/37
R519 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 79.3/38.8
R520 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 89.1/39.2
R521 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 84.2/40.4
R523 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 91.3/34.7
R524 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 86.9/37
R601 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 88.5/40
R602 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 91/39.6
R603 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 89.1/41
R604 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 78.6/45.9
R605 7030010040 S.RES ERJ2GEJ-JPW T 68.2/45.2
R606 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 67.1/47.4
R607 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 66.6/45.2
R701 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 61.1/53
R702 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 64.2/43.9
R703 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 50.8/44.1
R705 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 59/51.5
R706 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) T 64.5/55.9
R707 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 59.5/57
R708 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 63.9/58.6
R709 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) T 59.5/55.1
R710 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 59.8/62.5
R711 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 50.5/51.4
R712 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 51.2/50.5
R713 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 57.1/51.5
R715 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 52.1/54.1
R716 7030005710 S.RES ERJ2GEJ 121 X (120
Ω
) T 51.3/57.5
R717 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 52.1/51.4
R718 7510001461 S.TMR NTCG16 3NH 471JT T 63.3/54
R801 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 86.8/55.1
R802 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 65.3/60.9
R803 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 71.9/64.9
R804 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 91.1/57.1
R805 7030010090 S.RES ERJ2GEJ 180 X (18
Ω
) T 86.3/54.1
R806 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 85.2/55.1
R807 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 62.8/64.6
R808 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 62.3/69.4
R809 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 82.8/60.6
R810 7030010090 S.RES ERJ2GEJ 180 X (18
Ω
) T 84.4/60.6
R811 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 82.8/59.7
R904 7030003860 S.RES ERJ3GE JPW V T 36.5/68.1
R905 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 39.2/64.6
