M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R906 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 39.2/66.5
R907 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 36.8/70
R908 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 35.6/61.9
R909 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) T 34.2/68.4
R912 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) T 34.2/66.6
R913 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 40.5/75
R914 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) T 35.6/75.4
R915 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 36.6/70.9
R916 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 37.2/75.4
R917 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 34.2/69.3
R918 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 31.4/72.1
R919 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 31.5/72.1
R1009 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) T 25.8/72.9
R1018 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 18.1/73.7
R1019 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 20.3/76.9
R1020 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 12.7/77.6
R1022 7510001461 S.TMR NTCG16 3NH 471JT T 14.8/75.9
R1023 7030008370 S.RES ERJ2GEJ 561 X (560
Ω
) T 15.2/74.7
R1024 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 12.7/74.9
R1025 7030007260 S.RES ERJ2GEJ 330 X (33
Ω
) T 12.7/76.7
R1027 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 4.6/87.8
R1201 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 25.7/77.6
R1202 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 24/78.5
R1203 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 25.6/78.5
R1204 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 20.2/79.2
R1205 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 20.2/78.3
R1206 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 21.8/79.2
R1207 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 17.9/83.6
R1208 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 9.4/79.8
R1209 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 16.4/79.9
R1211 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 12.7/79.4
R1212 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 12.7/78.5
R1213 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 11.1/79.4
R1215 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) T 8.1/81.3
R1216 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 9.5/83.4
R1217 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 8/82.8
R1218 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 7.5/78.5
R1219 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 7.5/79.7
R1301 7030010040 S.RES ERJ2GEJ-JPW T 16.8/72.9
R1302 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 15.2/72.7
R1303 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 12.7/74
R1304 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 14.9/68.3
R1305 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 16.2/63.8
R1306 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 10.9/56.8
R1308 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 12.9/67.3
R1309 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 11.3/66.4
R1310 7510001451 S.TMR NTCG16 4BH 472JT T 12.2/68.4
R1401 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 45.3/72.3
R1402 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 43.6/72.3
R1403 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 44.5/73.4
R1404 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 44.5/75.2
R1405 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 42/71.5
R1406 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) B 38.7/79.9
R1407 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 38.7/79
R1408 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 38.7/80.8
R1409 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 34.6/80
R1414 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 20.2/76.4
R1416 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 19.4/83
R1420 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 25/76.8
R1421 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 23.2/75.9
R1422 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 23.2/76.8
R1501 7030010040 S.RES ERJ2GEJ-JPW B 72.4/38.2
R1502 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 86.4/55.3
R1503 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 85.7/54.1
R1504 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 72.4/40.3
R1505 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 73.6/54.8
R1506 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) B 85.7/52.3
R1507 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) B 85.7/53.2
R1508 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 74.2/61.6
R1509 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) B 85.9/59
R1510 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
)
[USA] only B 76.6/61.9
R1511 7030005590 S.RES ERJ2GEJ 680 X (68
Ω
) B 85.8/60.8
R1512 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 71.5/73.7
R1513 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 73.1/73.7
R1514 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 73.1/52.8
R1515 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 71.8/53.6
R1516 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 82.5/35.3
R1521 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 86.5/50.3
R1522 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 86.7/46.8
R1523 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 77.3/39.5
R1524 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 81.9/40.3
R1525 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 81.9/42.2
R1526 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 83.5/40.5
R1602 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 6.3/54
R1603 7030010040 S.RES ERJ2GEJ-JPW T 13/49.6
R1604 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 13/50.5
R1605 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 8.8/46.9
R1606 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 6.1/46.6
R1607 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 5.1/42.1
R1608 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 10.4/47.8
R1609 7030007320 S.RES ERJ2GEJ 225 X (2.2 M
Ω
) T 10.4/46
R1610 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 4.5/43.5
R1611 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 8.8/47.8
R1612 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 3.4/42.3
R1613 7030003860 S.RES ERJ3GE JPW V T 6.7/48.7
R1614 7030007310 S.RES ERJ2GEJ 155 X (1.5 M
Ω
) T 6.1/45.7
R1615 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 4.2/35.4
R1616 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 6.7/35.4
R1617 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) T 3.4/38.2
R1618 7310005020 S.TRI RH03ADC14X (10 k
Ω
) T 3.5/46.3
R1619 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) T 2.6/43.3
R1620 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 3.4/37.3
R1621 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 6.7/37.2
R1622 7030010040 S.RES ERJ2GEJ-JPW T 5/37.3
R1623 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 12/46.8
R1624 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) T 14.9/38.3
R1625 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 13.6/32.6
R1626 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 10.3/34.5
R1627 7030007320 S.RES ERJ2GEJ 225 X (2.2 M
Ω
) T 10.3/35.4
R1628 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 4.9/30.8
R1629 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 4.9/29.9
R1630 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 8.3/45.7
R1631 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 9.8/37.2
R1634 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 10.3/33.6
R1636 7030007320 S.RES ERJ2GEJ 225 X (2.2 M
Ω
) T 13/31.7
R1637 7030007320 S.RES ERJ2GEJ 225 X (2.2 M
Ω
) T 12/45.9
R1638 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 10.9/48.8
R1639 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 14.6/50.5
R1640 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 10.9/31.6
R1641 7030007320 S.RES ERJ2GEJ 225 X (2.2 M
Ω
) T 13/30.7
R1642 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 56/24
R1701 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) T 48/45.3
R1702 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 52.1/44.7
R1703 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 53.7/43.8
R1704 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 53.7/44.7
R1705 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) T 48/46.2
R1706 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 53.6/64.2
R1707 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 55.6/64.8
R1708 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 55.6/65.7
R1901 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 20/13.9
R1902 7030011290 S.RES ERJ12YJ1R8U (1.8
Ω
) B 12.4/45.8
R1952 7030009980 S.RES ERJ12RSJR15U B 42.6/102.7
R1953 7030009980 S.RES ERJ12RSJR15U B 42.6/99
R1954 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 42.7/111.3
R1955 7030005511 S.RES ERA3YED 303V (30 k
Ω
) B 44.9/108
R1956 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 33.7/105.1
R1957 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) B 35.3/104.2
R1958 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 35.3/103.3
R1981 7030008240 S.RES ERJ12YJ0R00U B 83.1/109
R2002 7030010040 S.RES ERJ2GEJ-JPW B 36.9/12.7
R2003 7030008240 S.RES ERJ12YJ0R00U T 55.7/8
R2004 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 59.8/9.2
R2005 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 59.1/3
R2006 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 60.7/3.7
R2007 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 60.7/4.6
R2008 7030010040 S.RES ERJ2GEJ-JPW B 34/17.6
R2010 7030010040 S.RES ERJ2GEJ-JPW B 32.5/15.1
R2011 7030006210 S.RES ERJ12YJ4R7U (4.7
Ω
) B 13.1/26.3
R2012 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 32.4/17.3
R2101 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 26.1/113.8
R2102 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 33.1/114.3
R2103 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 30.7/123.4
R2104 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 28.1/123.4
R2105 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 32.3/119
R2106 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) T 25/115.5
R2107 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) T 31.5/114.8
R2108 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 30.7/122.5
R2109 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) T 27.1/122.5
R2110 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 44.3/111.8
R2111 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 44.7/110
R2112 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 54.1/110.8
R2113 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 54.1/111.7
R2114 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 44.7/112.7
R2115 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 44.7/109.1
R2116 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 54.4/109.9
R2117 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 54.1/112.6
R2118 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 54.1/120.6
R2119 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 54.1/121.8
R2120 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 44.8/122.1
R2121 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 42.9/121.3
R2122 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 54.1/119.7
R2123 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) T 54.2/122.8
R2124 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 44.8/123
R2125 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 44.8/119.4
R2126 7030010040 S.RES ERJ2GEJ-JPW T 33.1/116.6
R2128 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 32.3/123.4
R2129 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 54.1/118.8
R2131 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 39.8/122
R2132 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 42.8/115.1
R2133 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 40.6/114.1
R2134 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 36.5/114.1
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
To Next Page
Loading...
