5 - 8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
R2135 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 34.9/114.2
R2136 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 26.5/123.4
R2137 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 43.3/123.7
R2138 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 42.9/122.2
R2139 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 25/116.4
R2140 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 32/115.7
R2141 7030010040 S.RES ERJ2GEJ-JPW T 44.7/113.6
R2142 7030010040 S.RES ERJ2GEJ-JPW T 52.7/108.9
R2143 7030010040 S.RES ERJ2GEJ-JPW T 56/109.9
R2144 7030010040 S.RES ERJ2GEJ-JPW T 51.3/115.1
R2145 7030010040 S.RES ERJ2GEJ-JPW T 58.1/123.6
R2146 7030010040 S.RES ERJ2GEJ-JPW T 46.3/124
R2147 7030010040 S.RES ERJ2GEJ-JPW T 46/118.5
R2151 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 52.3/101.7
R2152 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 56.5/107.1
R2153 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 24.8/112.5
R2154 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 25.6/111.6
R2155 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 46.1/104.6
R2156 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 46.1/105.5
R2157 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 33.3/120.8
R2158 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 33.3/119.8
R2159 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 35/118.3
R2160 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 40.7/94.3
R2161 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 40.7/95.2
R2162 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 30.2/93.8
R2163 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 30.9/95.9
R2164 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 30.2/94.7
R2165 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 29.3/95.9
R2166 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 51.8/93.3
R2167 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 51.8/94.2
R2168 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 51.8/95.1
R2169 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 8.8/118.5
R2170 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 5/104.5
R2171 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 9.7/114.2
R2172 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 5/112.4
R2174 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 5/105.4
R2175 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 5/111.5
R2176 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 11.3/114.2
R2177 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) T 3.3/108
R2202 7030010040 S.RES ERJ2GEJ-JPW T 26.5/124.3
R2203 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) T 25/122.4
R2204 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 23.4/122.7
R2205 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 18.2/118.2
R2206 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) T 12.6/118.8
R2207 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 23.1/121.5
R2208 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 19/119.2
R2209 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 21/116.5
R2211 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 12.9/123.5
R2212 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 12/124.4
R2213 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 10.4/124.4
R2214 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 8.8/117.6
R2215 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 11.1/120.6
R2217 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) T 24.9/121.5
R2218 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) T 15.5/127.5
R2219 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) T 17.7/126.1
R2220 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 16.1/126.1
R2221 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 9.5/120.5
R2230 7030010900 S.RES ERJ3GEYJ 750 V (75
Ω
) T 40.4/105.8
R2231 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 4.5/118.2
R2232 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 54.7/117.5
R2251 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 6.1/96.9
R2254 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 6.8/100.7
R2255 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 6.8/101.6
R2256 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 6.8/102.5
R2257 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 75.3/109
R2258 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 70.9/106.5
R2259 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 75.3/107.8
R2260 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 71/105.6
R2261 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 75.3/106.6
R2262 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 71.4/104.5
R2263 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 75.6/104.5
R2264 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 72.2/103.6
R2267 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 78.6/104.1
R2268 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 78.6/103.2
R2269 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 78.6/102.3
R2270 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 76.6/101.8
R2271 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 76.6/100.9
R2272 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 78.1/97.8
R2273 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 78.1/98.9
R2274 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 14.1/89.7
R2277 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 19.2/89.5
R2278 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 19.2/90.4
R2279 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 66.2/107
R2280 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 69.7/110.2
R2281 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 7.1/101.5
R2301 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) T 28.3/106.6
R2302 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 28.9/108
R2303 7030005710 S.RES ERJ2GEJ 121 X (120
Ω
) T 31.2/110.8
R2304 7030010900 S.RES ERJ3GEYJ 750 V (75
Ω
) T 77.7/112
R2311 7030006101 S.RES ERA3YED 183V (18 k
Ω
) B 67.6/107.1
R2312 7030006571 S.RES ERA3YED 392V (3.9 k
Ω
) B 68.5/108.3
R2401 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 78.7/29.6
R2402 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 81.3/29.6
R2405 7030010040 S.RES ERJ2GEJ-JPW T 91.9/5.8
R2406 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 90.3/100.7
R2408 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 90.3/99.8
R2409 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 87.1/68.1
R2410 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 90.3/65.5
R2411 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 87.3/67.2
R2412 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 91.3/68.5
R2413 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 87.3/66.3
R2414 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 90.3/64.6
R2415 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 87.3/65.4
R2416 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 90.3/63.7
R2417 7030010040 S.RES ERJ2GEJ-JPW B 43/141.4
R2418 7030010040 S.RES ERJ2GEJ-JPW T 93.3/7.8
R2501 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 8.3/93.3
R2502 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 8/95.1
R2503 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 8/91.5
R2505 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 10.6/89.2
R2506 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 9.4/90
R2507 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 16.4/89.9
R2508 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 10.4/88.3
R2509 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 15.7/88.3
R2510 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 17.4/92.8
R2513 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 15.8/94
R2551 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 42.9/123.2
R2552 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 42.9/122.3
R2555 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 51.4/119.3
R2556 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 44.5/125.2
R2559 7030010040 S.RES ERJ2GEJ-JPW B 49.5/124.6
R2560 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 49.5/125.5
R2561 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 52.9/124.7
R2562 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 53.9/122.8
R2564 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 46.1/126.1
R2565 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) B 42/117
R2566 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 59/126.8
R2567 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 60.6/126.8
R2568 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 47.8/124.7
R2569 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 46.1/125.2
R2601 7030010040 S.RES ERJ2GEJ-JPW B 66.7/123.4
R2602 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 57.2/122.6
R2603 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 63.4/121.7
R2604 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) B 66.7/124.3
R2605 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 65.5/126
R2607 7030010040 S.RES ERJ2GEJ-JPW T 40.4/132.4
R2608 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 85.4/134.1
R2611 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 33.9/125.2
R2612 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 38.4/126
R2613 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) B 38.4/124.2
R2614 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 34.5/127.2
R2617 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 63.3/111.1
R2618 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 69.3/112.6
R2619 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 63.3/112.1
R2620 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 78.1/100.3
R2621 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 78.1/99.4
R2623 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 9.8/112.9
R2624 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 86.8/122
R2628 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 61.8/121.7
C5 4030017460 S.CER ECJ0EB1E102K B 47.5/30.7
C6 4030018960 S.CER C3216 JB 1C 106MT-N T 66.3/12
C7 4030017330 S.CER ECJ0EF1C104Z T 73.1/13.2
C8 4030017330 S.CER ECJ0EF1C104Z T 77.2/9
C9 4030017330 S.CER ECJ0EF1C104Z T 73.1/15
C10 4030017330 S.CER ECJ0EF1C104Z T 75/15.5
C11 4030017330 S.CER ECJ0EF1C104Z T 72.7/20.1
C12 4030017330 S.CER ECJ0EF1C104Z T 76.8/16.7
C13 4030017330 S.CER ECJ0EF1C104Z T 73.4/18.3
C14 4030017460 S.CER ECJ0EB1E102K T 67.7/16.5
C15 4030017460 S.CER ECJ0EB1E102K T 63.7/15.6
C16 4030017460 S.CER ECJ0EB1E102K T 63.6/16.5
C17 4030017460 S.CER ECJ0EB1E102K T 60.7/16.7
C18 4030017620 S.CER ECJ0EC1H100C T 60.8/19
C21 4030017730 S.CER ECJ0EB1E471K T 63.7/14.7
C25 4030017580 S.CER ECJ0EC1H060C T 55.2/17.8
C26 4030017660 S.CER ECJ0EC1H330J T 55.2/18.7
C27 4030017780 S.CER ECJ0EB1E472K T 51.6/20.5
C28 4030017530 S.CER ECJ0EC1H0R5B T 53.8/17.1
C29 4030017600 S.CER ECJ0EC1H080C T 51.7/19.6
C30 4030017730 S.CER ECJ0EB1E471K T 45.8/17.5
C31 4030017530 S.CER ECJ0EC1H0R5B T 53.8/16.2
C32 4030017660 S.CER ECJ0EC1H330J T 52.1/17.4
C33 4030017580 S.CER ECJ0EC1H060C T 52.2/16.5
C34 4030017380 S.CER ECJ0EC1H050B T 56/15
C35 4030017380 S.CER ECJ0EC1H050B T 55.9/12.4
C36 4030017730 S.CER ECJ0EB1E471K T 51/15.6
C37 4030017780 S.CER ECJ0EB1E472K T 70.4/10.6
C38 4030017780 S.CER ECJ0EB1E472K T 45.8/18.4
C40 4030017730 S.CER ECJ0EB1E471K T 73.1/14.1
C41 4030017730 S.CER ECJ0EB1E471K T 66.8/19.6
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
