Icom IC-7000 Service Manual

5 - 17
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[PA UNIT]
EP759 6910012350 S.BEA MMZ1608Y 102BT T 69.1/9.6
EP760 6910012350 S.BEA MMZ1608Y 102BT T 60.6/10
EP761 6910012350 S.BEA MMZ1608Y 102BT T 62.5/9.6
EP762 6910012350 S.BEA MMZ1608Y 102BT B 61/4.6
EP763 6910012350 S.BEA MMZ1608Y 102BT B 63.3/105.6
EP767 6910012350 S.BEA MMZ1608Y 102BT B 76.4/5.2
EP772 6910012350 S.BEA MMZ1608Y 102BT T 96.4/3.8
EP774 6910012350 S.BEA MMZ1608Y 102BT T 72.8/9.6
EP775 6910012350 S.BEA MMZ1608Y 102BT B 74.8/5.2
EP776 6910012350 S.BEA MMZ1608Y 102BT B 73.2/5.2
EP777 6910012350 S.BEA MMZ1608Y 102BT B 70/5.2
EP778 6910012350 S.BEA MMZ1608Y 102BT B 71.6/5.2
EP779 6910012350 S.BEA MMZ1608Y 102BT B 68.2/5.2
IC1 1130013280 S.IC TC58FVM6T5BTG65GCH T 27.9/30.2
IC2 1130011151 S.IC SN74AHC2G08HDCT3 B 40.2/38.2
IC3 1130011151 S.IC SN74AHC2G08HDCT3 B 40.2/32.5
IC4 1130012600 S.IC SN74AHC1G04DCKR B 43.3/33.8
IC51 1130012841 S.IC CY7C1021CV33-15BAXIT B 24.5/28.5
IC301 1140012541 S.IC ADSP-BF532SBBCZ400 B 28.6/39.2
IC401 1110004770 S.IC BU9480F-E2 B 17.4/21.6
IC451 1110006570 S.IC TS462CPT B 29.1/7.9
IC452 1110006570 S.IC TS462CPT T 39.1/8.5
IC502 1110006570 S.IC TS462CPT T 30.7/5.4
IC551 1190001611 S.IC AK4528VFP-E2/P T 17.9/8.1
IC601 1110006570 S.IC TS462CPT B 12.7/10.8
IC701 1130012600 S.IC SN74AHC1G04DCKR B 2.7/15.9
IC1201 1130012791 S.IC CY22150FZXCT B 44.5/4.5
IC1212 1140012170 S.IC BH7236AF-E2 T 57.7/7.3
IC1217 1130007181 S.IC TC7WU04FU (TE12L, F) B 63.4/9.8
IC1218 1130012760 S.IC SN74AHC2G86HDCTR B 52.7/6.5
IC1226 1130010870 S.IC S1D13706F00A B 53.7/19.8
IC1251 1180002020 S.REG BA033FP-E2 T 79.5/5.2
IC1301 1130012690 S.IC HN58X24256FPIE (SOP8) T 81.4/36.2
IC1302 1140013133 S.IC HD64F2377VFQ33V T 54.9/25.2
IC1303 1110005771 S.IC S-80942CNMC-G9CT2G T 81.2/10.4
IC1304 1130011551 S.IC RX-4581NB-F B 71.9/7.2
IC1402 1130012780 S.IC SN74AHC2G04HDCTR T 79.1/18.9
IC2002 1130012841 S.IC CY7C1021CV33-15BAXIT B 32.7/28.3
IC2101 1130012850 S.IC SN74LVC3G34DCUR T 44.5/44.7
IC2102 1130012850 S.IC SN74LVC3G34DCUR T 44.4/41.2
IC2201 1140012541 S.IC ADSP-BF532SBBCZ400 B 28.6/17.7
Q201 1550000110 S.FET RTQ035P02TR B 18.9/42.7
Q1101 1530002060 S.TR 2SC4081 T106 R T 82.1/20.3
Q1102 1590003520 S.TR BCR108T T 81.8/22.7
Q1103 1510000510 S.TR 2SA1576A T106R T 81.8/16.4
Q1201 1590003520 S.TR BCR108T T 44.8/13.2
D201 1750001280 S.DIO CUS02 (TE85L,Q) B 19.2/45.3
D1001 1750000370 S.DIO DA221 TL B 64.5/36.8
D1002 1750000370 S.DIO DA221 TL B 64.9/34.5
D1101 1790001250 S.DIO MA2S111-(TX) T 81.9/18.4
D1106 1750000950 S.DIO MA732 (TX) T 80.1/29.6
D1107 1790001670 S.DIO RB706F-40T106 T 82.4/31.3
D1110 1790001670 S.DIO RB706F-40T106 T 75.7/32.3
D1111 1790001670 S.DIO RB706F-40T106 T 75.3/29.3
D1112 1790001670 S.DIO RB706F-40T106 B 79.2/29.1
D1113 1790001670 S.DIO RB706F-40T106 B 82.3/30.6
D1201 1790001250 S.DIO MA2S111-(TX) B 83/40.4
D1301 1790000660 S.DIO MA728 (TX) B 77.5/2.9
D1304 1750000370 S.DIO DA221 TL T 76.1/19.9
D1305 1750000370 S.DIO DA221 TL T 75.8/16.8
D1306 1750000370 S.DIO DA221 TL B 49.3/32.9
D1307 1750000370 S.DIO DA221 TL B 51.4/33.3
D1311 1790001250 S.DIO MA2S111-(TX) B 80.9/19.6
D1312 1790001250 S.DIO MA2S111-(TX) B 83.1/18.5
D1313 1790001250 S.DIO MA2S111-(TX) B 80/22.6
D1314 1790001240 S.DIO MA2S728-(TX) B 81.7/22.4
D1331 1790001250 S.DIO MA2S111-(TX) B 65.6/17.5
X1201 6050012140 S.XTL CR-805 [USA] B 61.3/3.1
6050012150 S.XTL CR-806 [Others] B 61.3/3.1
X1301 6050012190 S.XTL CR-809 B 60.4/30.8
L201 6200011900 S.COL LQH43CN100K03L T 16/41.9
L202 6200009491 S.COL CDRH6D28NP-100NC B 13.3/41.4
L551 6200005011 S.COL NLV25T-100J T 11/9.8
L552 6200005011 S.COL NLV25T-100J T 10.4/5.8
L1202 6200002041 S.COL NLV25T-101J B 52.3/2.3
L1203 6200002041 S.COL NLV25T-101J T 66.7/3.5
L1204 6200002041 S.COL NLV25T-101J B 57.9/10.3
L2101 6200005011 S.COL NLV25T-100J T 40.9/45
L2102 6200005011 S.COL NLV25T-100J T 40.2/41.5
R2 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 39.5/30.1
R3 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 39.5/32.3
R4 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 31.8/45.8
R5 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 30.9/45.8
R6 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 30/45.8
R203 7030000010 S.RES MCR10EZHJ JPW T 20.7/45.6
R301 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 25.4/45.8
R302 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 26.9/45.8
R303 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 27.8/45.8
R306 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 37.3/32.2
R307 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 22/41.4
R308 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 22/40.5
R310 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 36.7/35.4
R312 7030010040 S.RES ERJ2GEJ-JPW B 33.6/45.9
R313 7030010040 S.RES ERJ2GEJ-JPW B 35.6/43.3
S.=Surface mount
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[DRIVER UNIT]
Q504 1590003060 S.FET PD55015 T 20/9.7
R102 7070000271 RES ERG1SJ 101 (100
Ω
)
C101 4030004750 S.CER C2012 JB 1H 103K-T T 24.6/18.2
C102 4030011230 S.CER GRM31M2C2H390JV01L T 11.2/4.2
J101 6910016830 CNR IMSA-9230B-1-04Z149-PT1
J102 6910016830 CNR IMSA-9230B-1-04Z149-PT1
J103 6910016830 CNR IMSA-9230B-1-04Z149-PT1
J104 6910016830 CNR IMSA-9230B-1-04Z149-PT1
J107 6910016830 CNR IMSA-9230B-1-04Z149-PT1
