Icom IC-7000 Service Manual

5 - 18
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]
R314 7030010040 S.RES ERJ2GEJ-JPW B 35.6/40.6
R413 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 18.1/16.8
R414 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 16.3/19.9
R415 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 19/16.8
R416 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 17.2/16.8
R462 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 33.8/7.4
R463 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 43.6/8.8
R464 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 26.2/5.7
R465 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) B 28.6/5.2
R467 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 31.3/4.3
R469 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) B 30.4/4.3
R470 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 29.4/3
R471 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 34/3.3
R472 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 38.6/4.2
R473 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 38.6/3.2
R474 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) B 24.8/7.1
R475 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) B 33.8/9.2
R476 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 40.2/3.3
R507 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 26/3.5
R508 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 31.6/8.9
R510 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 32.5/8.9
R511 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 28.9/8.9
R512 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 29.8/8.9
R514 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 34.9/8.8
R515 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 34.9/7.9
R516 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 39/12.8
R517 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 36.5/11
R518 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 36.4/5.6
R519 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 26.4/5.6
R520 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 41.3/12.8
R551 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 16.5/13.4
R553 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 14.7/13.4
R554 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 15.4/3.2
R568 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 12.9/13.4
R569 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 15.6/13.4
R570 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 13.8/13.4
R571 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 20.7/8.4
R601 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 6.2/12.6
R602 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 9.2/9.2
R603 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 12.3/4.8
R604 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 13.2/4.8
R605 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 14.4/5.1
R606 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 12.8/7.2
R607 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) B 13.8/7.2
R608 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) B 14.8/6.4
R609 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 3.3/12.4
R610 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 8.9/4.2
R611 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 9.8/4.2
R612 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 11.4/5.6
R613 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 8.8/6.9
R614 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) B 9.7/6.9
R615 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) B 10.6/6.9
R618 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 14.4/4.2
R619 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 10.7/4.2
R701 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 4.6/22.8
R702 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 4.6/23.7
R703 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 4.5/25.9
R705 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 5/21
R706 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 4.4/17.1
R707 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) B 4.4/15.5
R1001 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 70.8/37
R1002 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 65.9/32.3
R1003 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 70.4/35.8
R1004 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 66.1/18.5
R1006 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 52/34.8
R1007 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 53.2/32
R1008 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 75.1/20.4
R1010 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 76.7/19.8
R1012 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 66.5/34.2
R1013 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 66.5/36.2
R1015 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 50.4/34.8
R1016 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 51/31.7
R1018 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 63.3/34.4
R1019 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 62.9/36.1
R1101 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 80.1/15.4
R1102 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 79.9/21.9
R1103 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 79.9/22.8
R1104 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 74.5/20.7
R1105 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 79.6/14.2
R1106 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 83.3/14.4
R1107 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 79.2/15.4
R1108 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 78.3/14.8
R1109 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 78.3/21.9
R1110 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 76.7/21.4
R1111 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 77.4/14.8
R1113 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 83.2/29.3
R1114 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 82.3/29.3
R1115 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 76.8/26.3
R1116 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 76.9/28.1
R1117 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 82.7/22.2
R1118 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 83/23.8
R1119 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 83.8/22.2
R1120 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 84.1/23.8
R1123 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 66.9/24.4
R1124 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 82/20
R1126 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 66.9/23.5
R1127 7030010040 S.RES ERJ2GEJ-JPW T 73.7/18.5
R1128 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 83.2/20.1
R1129 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 81.9/28.4
R1131 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 78.5/26.1
R1132 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 81.4/24.4
R1201 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 62.7/7.6
R1202 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 49.2/7.5
R1203 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 49.2/8.4
R1204 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 49.7/9.6
R1205 7030010040 S.RES ERJ2GEJ-JPW B 49.2/3.1
R1206 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) B 46.1/9.6
R1207 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) B 43.9/9.6
R1208 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) B 43.5/11.4
R1209 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
) B 48.8/9.6
R1210 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) B 47.9/9.6
R1211 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 48.9/11.4
R1212 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 48/11.4
R1213 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 47.1/11.4
R1214 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
) B 46.2/11.4
R1215 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) B 45.3/11.4
R1216 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 44.7/12.6
R1217 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 44.7/13.5
R1218 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 44.7/14.4
R1219 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 74.4/41.1
R1220 7030009710 S.RES ERJ2GEJ 203 X (20 k
Ω
) B 44.7/15.3
R1221 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 82.9/41.6
R1222 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 74.4/40.2
R1223 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 74.4/39.3
R1224 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 82.9/39.3
R1225 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 83.1/35.7
R1226 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 74.4/37.5
R1227 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 73.8/38.4
R1228 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 82.2/35.7
R1229 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) B 43.5/15.4
R1230 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 49.2/2.2
R1231 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 48.8/5.4
R1232 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 40.3/3.2
R1235 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) T 66.2/5.9
R1236 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) T 66.2/7
R1237 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 61.1/7.6
R1251 7030011250 S.RES ERJ1TY 390U (39
Ω
) T 70.3/5.8
R1301 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 78.1/37.8
R1302 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 78.1/36
R1303 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 66/21.2
R1304 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 66/20.3
R1305 7030009160 S.RES ERJ2GEJ 181 X (180
Ω
) T 68.5/25.9
R1306 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 78.7/11.4
R1307 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 68/21.9
R1308 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 67.5/20
R1309 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 69/19.4
R1310 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 67.5/18.8
R1311 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 69/18.2
R1312 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 67.5/17.6
R1313 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 69/17
R1314 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 67.5/16.4
R1315 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 69/15.8
R1316 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 66.6/12.3
R1317 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 65.7/12.3
R1318 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 64.8/12.3
R1319 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 63.9/12.3
R1320 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 63/12.3
R1321 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 62.1/12.3
R1322 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 61.2/12.3
R1323 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 60.3/12.1
R1324 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 80.5/12.6
R1325 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) T 78.1/9.8
R1326 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 78.9/2
R1327 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 66/19.4
R1328 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 75.9/6.4
R1329 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 75.9/5
R1331 7030010040 S.RES ERJ2GEJ-JPW B 75.9/3.2
R1332 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 75.9/4.1
R1333 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 67.4/26.9
R1334 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 78.3/12.6
R1335 7030010040 S.RES ERJ2GEJ-JPW B 78.5/5.1
R1337 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 40.9/15.5
R1338 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 40.9/16.4
R1339 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 65.5/22.4
R1401 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 62.7/24.2
R1402 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 76.7/21.8
R1403 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 78.3/22.1
R1404 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 76.7/22.9
R1405 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 50.7/12.9
R1406 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 69/20.6
R1407 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 41.7/33.4
R1408 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 76.7/25.3
S.=Surface mount
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]

Icom IC-7000 Specifications

General

Input voltage	13.8 V
Microphone included	Yes
Product type	Portable CB radio
Product color	Black
Housing material	-
Frequency range	0.5 - 455000 MHz
Channels quantity	503 channels

Weight and Dimensions

Depth	180 mm
Width	167 mm
Height	58 mm
