Feb. 2009
59
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MEMORY BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
J904 6510017930 CNR 1771P145-20
J905 6510019421 S.CNR B8B-ZR-SM4-TF (LF) (SN) T 146.8/160.2
IC1 1130013514 S.IC JS28F128J3D-75(SX-2590A-8) T 39.8/26.2
IC2 1130013515 S.IC JS28F128J3D-75(SX-2590A-9) T 24/26.2
C1 4030011600 S.CER C1608 JB 1E 104K-T T 41.8/38.8
C2 4030011600 S.CER C1608 JB 1E 104K-T T 39.9/13.2
C3 4030011600 S.CER C1608 JB 1E 104K-T T 36.8/13.2
C4 4030011600 S.CER C1608 JB 1E 104K-T T 26/38.8
C5 4030011600 S.CER C1608 JB 1E 104K-T T 24/13.2
C6 4030011600 S.CER C1608 JB 1E 104K-T T 21/13.2
J1 6510024210 S.CNR AXK6S30435P T 55/20
J2 6510024200 S.CNR AXK6S40435P T 10/20
S.=Surface mount
To Next Page
