SECTION 6 MECHANICAL PARTS AND DISSASEMBLY
MF1 2710000760 Fan FD1240107B-1N 1
SP1 2510001260 2590 SP box 1
MP1 8930040720 1768 B-clip 1
MP2 8930061281 2590 ant angle-1 1
MP3 8930061840 2590 A-stand sheet 2
MP4 8510016031 2590 BPF case-1 1
MP5 8510016040 2590 BPF S-cover 1
MP6 8010019283 2590 Chassis-3 1
MP7 8930061720 2590 DIGISEL plate 1
MP8 8930062320 2590 A-DIGISEL sponge 1
MP10 8510015851 2590 FILTER case-1 1
MP11 8110008082 2590 L-cover-2 1
MP12 8110008091 2590 LOGIC cover-1 1
MP13 8930061350 2590 main stand 2
MP14 8930061960 2590 M-fan angle 1
MP15 8930061761 2590 M-jack angle-1 1
MP16 8510016101 2590 PLL plate-1 2
MP17 8510016010 2590 P-R cover 1
MP18 8210020460 2590 rear panel 1
MP20 8510015860 2590 SCOPE cover 1
MP21 8210019820 2590 side panel 2
MP22 8930062010 2590 S-jack angle 1
MP23 8930061950 2590 SP angle 1
MP27 8110008072 2590 U-cover-2 1
MP101 8810007231 Setscrew H M3 × 8 ZC3 4
MP102 8810007231 Setscrew H M3 × 8 ZC3 1
MP103 8810009111 Screw PH M2.6 × 16 ZK3 2
MP104 8810005771 Screw BiH M3 × 8 ZK3 2
MP105 8810005771 Screw BiH M3 × 8 ZK3 2
MP106 8810008451 Screw BiH M4 × 8 ZK3 4
MP107 8810005771 Screw BiH M3 × 8 ZK3 8
MP108 8810008451 Screw BiH M4 × 8 ZK3 14
MP109 8810008451 Screw BiH M4 × 8 ZK3 13
MP110 8810008451 Screw BiH M4 × 8 ZK3 4
MP111 8810008451 Screw BiH M4 × 8 ZK3 2
MP112 8810008451 Screw BiH M4 × 8 ZK3 2
MP113 8930011680 Rubber foot (G) 2
MP114 8810009651 Screw FH BT M3 × 8 NI-ZC3 20
MP115 8810009651 Screw FH BT M3 × 8 NI-ZC3 4
MP116 8810009461 Screw FH M3 × 8 ZK 4
MP117 8810009461 Screw FH M3 × 8 ZK 2
MP118 8810009461 Screw FH M3 × 8 ZK 1
MP119 8810009461 Screw FH M3 × 8 ZK 4
MP120 8810008630 Screw PH BT M3 × 6 NI-ZU 6
MP121 8810008661 Screw PH BT M3 × 8 NI-ZC3 14
MP122 8810008661 Screw PH BT M3 × 8 NI-ZC3 7
MP123 8810008661 Screw PH BT M3 × 8 NI-ZC3 5
MP124 8810008661 Screw PH BT M3 × 8 NI-ZC3 26
MP125 8810008661 Screw PH BT M3 × 8 NI-ZC3 7
MP126 8810008661 Screw PH BT M3 × 8 NI-ZC3 6
MP127 8810008661 Screw PH BT M3 × 8 NI-ZC3 4
MP128 8810008661 Screw PH BT M3 × 8 NI-ZC3 3
MP129 8810008661 Screw PH BT M3 × 8 NI-ZC3 2
MP130 8810008661 Screw PH BT M3 × 8 NI-ZC3 2
MP131 8810008661 Screw PH BT M3 × 8 NI-ZC3 4
MP132 8810008661 Screw PH BT M3 × 8 NI-ZC3 7
MP133 8810008661 Screw PH BT M3 × 8 NI-ZC3 2
MP135 8810008661 Screw PH BT M3 × 8 NI-ZC3 4
MP136 8810008661 Screw PH BT M3 × 8 NI-ZC3 2
MP137 8810008661 Screw PH BT M3 × 8 NI-ZC3 1
MP138 8810008661 Screw PH BT M3 × 8 NI-ZC3 4
MP139 8810008661 Screw PH BT M3 × 8 NI-ZC3 4
MP140 8810008661 Screw PH BT M3 × 8 NI-ZC3 11
MP141 8810004431 Screw PH M3 × 6 ZK3 2
[CHASSIS PARTS]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
MP142 8810004431 Screw PH M3 × 6 ZK3 4
MP143 8810009991 Screw PH BT M3 × 8 ZK3 1
MP144 8810004431 Screw PH M3 × 6 ZK3 4
MP145 8810008391 Screw PH M4 × 12 ZC3 2
MP146 8830000360 Wing nut M5 NI 1
MP147 8930028390 Himelon sheet AH 1
MP148 8850000150 Flat washer M5 NI BS 2
MP150 8930049850 2240 D-sponge 3.5 × 5 × 50 1
MP151 8930049850 2240 D-sponge 3.5 × 5 × 50 1
MP152 8930017190 Earth spring (F) 1
MP153 8930017190 Earth spring (F) 1
MP154 8510016281 2590 K-plate-1 1
MP155 8930056160 Double side tape (AG) 4
MP156 8810004431 Screw PH M3 × 6 ZK3 1
MP157 8930065730 2590E-earth 1
MP158 8930062720 Sponge (HS) 1
MP159 8930062270 2590 A-net 1
MP160 8930062280 2590 B-net 1
MP161 8930062290 2590 C-net 1
MP162 8930062360 2590 D-net 1
MP163 8930006960 Sponge (Y) 1
MP164 8930062770 Himelon sheet (CN) 1
MP165 8930058170 Shield sponge (O) 1
MP166 8930058170 Shield sponge (O) 1
MP167 8930017190 Earth spring (F) 1
MP169 8930063220 AL sheet (AJ) 1
MP171 8930028840 Sponge (DF) 1
MP172 8930056020 Sponge (GU) 1
MP173 8930056020 Sponge (GU) 1
MP174 8930048960 Shield tape (B) 2
MP175 8930056020 Sponge (GU) 2
MP178 8950002460 Other item S-10 1
MP179 8930063450 Shield sponge (AG) 6
MP180 8930063260 Sponge (HV) 1
MP181 8930056401 Shield sponge (H)-1 1
MP182 8930063700 AL sheet (AL) (for chassis W9) 1
MP184 8930061490 Shield sponge (AB) 1
MP185 8930063780 Shield sponge (AJ) 1
MP186 8930058840 Shield sponge (T) 1
MP187 6910008240 Clip 59TN4772 1
MP188 8930063560 Emboss tape (O) 4
[CHASSIS PARTS]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
6 - 1
Screw abbreviations BT: Self-tapping PH: Pan head
FH: Flat head BiH: Binding head
ZK: Black BS: Brass
NI: Nickel SUS: Stainless
NI-ZU: Nickel-Zinc
