5 - 23
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[RXPLL-B UNIT]
J2 6510019991 S.CNR 52808-2271 (2291) T 25/9
J10 6510007020 CNR TMP-J01X-V6
J351 6510007020 CNR TMP-J01X-V6
J561 6510007020 CNR TMP-J01X-V6
J601 6510007020 CNR TMP-J01X-V6
J681 6510007020 CNR TMP-J01X-V6
J831 6510007020 CNR TMP-J01X-V6
J1002 6510007020 CNR TMP-J01X-V6
J1101 6510007020 CNR TMP-J01X-V6
J1201 6510007020 CNR TMP-J01X-V6
J1301 6510007020 CNR TMP-J01X-V6
J1501 6510018961 S.CNR B2B-PH-SM4-TB (LF) (SN) T 149.6/177.5
J1701 6510019981 S.CNR 52808-1671 (1690) T 168/177.2
W1052 9016201006 WIR 73/98/025/X98/X98
W1401 9029495075 JMP 73/98/020/X98/X98
W1411 7120000480 S.JMP MJP-0.4-T T 125.1/111.6
EP20 6910012350 S.BEA MMZ1608Y 102BT T 85.4/126
EP21 6910012350 S.BEA MMZ1608Y 102BT T 88.7/124
EP22 6910012350 S.BEA MMZ1608Y 102BT T 90/124
EP101 6910012350 S.BEA MMZ1608Y 102BT B 47.6/98.6
EP102 6910012350 S.BEA MMZ1608Y 102BT B 47.6/96.8
EP103 6910012350 S.BEA MMZ1608Y 102BT T 46/96.8
EP104 6910012350 S.BEA MMZ1608Y 102BT T 46/92.9
EP105 6910012350 S.BEA MMZ1608Y 102BT T 46/91.6
EP106 6910012350 S.BEA MMZ1608Y 102BT T 46/89
EP107 6910012350 S.BEA MMZ1608Y 102BT B 47.6/100.4
EP1701 6910012350 S.BEA MMZ1608Y 102BT T 170.1/163.5
EP1702 6910012350 S.BEA MMZ1608Y 102BT T 168.8/163.5
EP1801 6910012350 S.BEA MMZ1608Y 102BT B 153/132.7
EP1802 6910012350 S.BEA MMZ1608Y 102BT B 142.5/18.8
EP1804 6910012350 S.BEA MMZ1608Y 102BT B 112.5/138.7
EP1805 6910012350 S.BEA MMZ1608Y 102BT B 150.2/141.8
EP1806 6910012350 S.BEA MMZ1608Y 102BT B 128.6/64.3
EP1807 6910012350 S.BEA MMZ1608Y 102BT B 117.4/50.2
EP1808 6910012350 S.BEA MMZ1608Y 102BT B 137/166.9
EP1809 6910012350 S.BEA MMZ1608Y 102BT B 147.4/127.4
EP1810 6910012350 S.BEA MMZ1608Y 102BT B 131.3/64.2
EP1811 6910012350 S.BEA MMZ1608Y 102BT T 160.7/56.3
EP1812 6910012350 S.BEA MMZ1608Y 102BT B 153.5/137.4
EP1813 6910012350 S.BEA MMZ1608Y 102BT B 132.6/65.7
EP1814 6910012350 S.BEA MMZ1608Y 102BT B 147.2/22.3
EP1815 6910012350 S.BEA MMZ1608Y 102BT B 156/62.6
EP1816 6910012350 S.BEA MMZ1608Y 102BT B 160.4/20.9
EP1817 6910012350 S.BEA MMZ1608Y 102BT B 168.6/62.2
EP1818 6910012350 S.BEA MMZ1608Y 102BT B 151.2/133.2
EP1819 6910012350 S.BEA MMZ1608Y 102BT B 145.6/127.9
EP1820 6910012350 S.BEA MMZ1608Y 102BT B 148.6/19.8
EP1821 6910012350 S.BEA MMZ1608Y 102BT B 148.6/14.1
EP1825 6910012350 S.BEA MMZ1608Y 102BT B 126.6/7
EP1826 6910012350 S.BEA MMZ1608Y 102BT B 151.5/137.7
EP1830 6910012350 S.BEA MMZ1608Y 102BT B 141.3/135.2
EP1831 6910012350 S.BEA MMZ1608Y 102BT B 143.4/128.5
EP1832 6910012350 S.BEA MMZ1608Y 102BT B 149.2/137.5
EP1833 6910012350 S.BEA MMZ1608Y 102BT B 147.2/133.5
EP1834 6910012350 S.BEA MMZ1608Y 102BT T 115.8/108.3
EP1835 6910012350 S.BEA MMZ1608Y 102BT B 141.6/128.5
EP1836 6910012350 S.BEA MMZ1608Y 102BT T 111/110.2
EP1837 6910012350 S.BEA MMZ1608Y 102BT B 145.8/134.1
EP1838 6910012350 S.BEA MMZ1608Y 102BT T 116.3/106.1
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[BPF UNIT]
IC101 1130011510 S.IC BU2099FV-E2 T 9.5/77.6
IC102 1130011510 S.IC BU2099FV-E2 T 9.7/100.9
IC401 1130011510 S.IC BU2099FV-E2 T 10.3/39.3
IC402 1130011510 S.IC BU2099FV-E2 T 9.6/59.4
Q355 1590001330 S.TR DTA114EUA T106 T 191.6/68.1
Q381 1590000680 S.TR DTC114EUA T106 T 232/60.3
Q383 1590000680 S.TR DTC114EUA T106 T 229.2/51.9
Q384 1590000680 S.TR DTC114EUA T106 T 226.2/51.9
Q385 1590000680 S.TR DTC114EUA T106 T 233.1/54.7
Q386 1590000430 S.TR DTC144EUA T106 T 230.1/54.7
Q387 1590000680 S.TR DTC114EUA T106 T 228.8/60.2
Q401 1530002841 S.TR 2SC4116-Y (TE85R,F) T 234.5/108.2
Q402 1530002060 S.TR 2SC4081 T106 R B 224.2/99.2
Q403 1590001330 S.TR DTA114EUA T106 B 227.6/100.2
Q404 1590000430 S.TR DTC144EUA T106 T 232/108.2
Q855 1590001330 S.TR DTA114EUA T106 T 192/53
Q871 1590001330 S.TR DTA114EUA T106 B 234.6/18.8
Q872 1530002060 S.TR 2SC4081 T106 R B 231.2/19.5
Q873 1530002841 S.TR 2SC4116-Y (TE85R,F) B 231.2/16.6
Q874 1590000430 S.TR DTC144EUA T106 T 195.7/57.4
Q900 1590001330 S.TR DTA114EUA T106 B 217.4/116.1
Q901 1530003851 S.TR 2SC5551F-TD-E T 210.3/113.5
Q902 1590001330 S.TR DTA114EUA T106 T 200.6/115.1
Q903 1530003851 S.TR 2SC5551F-TD-E T 189.4/113.5
Q950 1590001330 S.TR DTA114EUA T106 B 215/3.2
Q951 1530003851 S.TR 2SC5551F-TD-E T 209.8/17.6
Q952 1590001330 S.TR DTA114EUA T106 B 199.1/4
Q953 1530003851 S.TR 2SC5551F-TD-E T 188.6/17.6
D1 1790001250 S.DIO MA2S111-(TX) T 184/75.2
D21 1790001250 S.DIO MA2S111-(TX) B 167.1/77.7
D51 1790001250 S.DIO MA2S111-(TX) T 163.7/68.6
D81 1790001250 S.DIO MA2S111-(TX) B 141.5/68.1
D111 1790001250 S.DIO MA2S111-(TX) T 107.4/67.6
D141 1790001250 S.DIO MA2S111-(TX) T 94.7/70.3
D171 1790001250 S.DIO MA2S111-(TX) B 81.6/74.3
D201 1790001250 S.DIO MA2S111-(TX) B 70.2/73.1
D231 1790001250 S.DIO MA2S111-(TX) T 49.4/69.1
D261 1790001250 S.DIO MA2S111-(TX) B 35.4/70.1
D291 1790001250 S.DIO MA2S111-(TX) B 203.9/71.9
D321 1790001250 S.DIO MA2S111-(TX) T 204/97.5
D351 1790001250 S.DIO MA2S111-(TX) T 189/94.9
D352 1790001250 S.DIO MA2S111-(TX) T 189/88.7
D353 1790001250 S.DIO MA2S111-(TX) T 189/82.5
D354 1790001250 S.DIO MA2S111-(TX) T 189/76.3
D355 1790001250 S.DIO MA2S111-(TX) T 193.9/66.2
D371 1790001250 S.DIO MA2S111-(TX) T 218.5/69.9
D373 1790001250 S.DIO MA2S111-(TX) B 239.8/116.1
D391 1750000581 S.DIO 1SV307 (TPH3,F) B 233.2/49.9
D392 1750000581 S.DIO 1SV307 (TPH3,F) B 236/52.9
D393 1750000581 S.DIO 1SV307 (TPH3,F) B 235.3/63.7
D401 1790001250 S.DIO MA2S111-(TX) B 225.6/95.5
D402 1790000980 S.DIO MA742 (TX) B 233.9/113.2
D501 1790001250 S.DIO MA2S111-(TX) B 184.1/45.6
D531 1790001250 S.DIO MA2S111-(TX) B 167.7/53.7
D561 1790001250 S.DIO MA2S111-(TX) B 164.4/42.5
D591 1790001250 S.DIO MA2S111-(TX) B 144.1/53.4
D621 1790001250 S.DIO MA2S111-(TX) T 107.6/52.6
D651 1790001250 S.DIO MA2S111-(TX) T 94.9/49.6
D681 1790001250 S.DIO MA2S111-(TX) B 81.5/45.7
D711 1790001250 S.DIO MA2S111-(TX) B 70/44.3
D741 1790001250 S.DIO MA2S111-(TX) B 51.4/50.5
D771 1790001250 S.DIO MA2S111-(TX) B 36.5/43.7
D801 1790001250 S.DIO MA2S111-(TX) B 203.8/47.4
D831 1790001250 S.DIO MA2S111-(TX) T 203.7/22.1
D851 1790001250 S.DIO MA2S111-(TX) T 189/27.9
D852 1790001250 S.DIO MA2S111-(TX) T 189/33.1
D853 1790001250 S.DIO MA2S111-(TX) T 189/39.3
D854 1790001250 S.DIO MA2S111-(TX) T 189/45.5
D855 1790001250 S.DIO MA2S111-(TX) T 194/52.8
D871 1790001250 S.DIO MA2S111-(TX) B 241.4/18
D872 1790000980 S.DIO MA742 (TX) B 247.7/15.6
D873 1790001250 S.DIO MA2S111-(TX) B 243/94.1
D900 1790001250 S.DIO MA2S111-(TX) B 218.9/100.4
D901 1790001250 S.DIO MA2S111-(TX) T 207.9/100.7
D902 1790001250 S.DIO MA2S111-(TX) B 197/100.2
D903 1790001250 S.DIO MA2S111-(TX) B 186.4/100.5
D950 1790001250 S.DIO MA2S111-(TX) B 212.3/3.9
D951 1790001250 S.DIO MA2S111-(TX) T 204.4/4.5
D952 1790001250 S.DIO MA2S111-(TX) B 195.7/4.9
D953 1790001250 S.DIO MA2S111-(TX) B 182.6/5.3
D954 1790001250 S.DIO MA2S111-(TX) T 235.4/16.2
L1 6200005521 S.COL NLV25T-470J T 186.7/100.6
L2 6200005521 S.COL NLV25T-470J B 183.8/77.2
L3 6200010830 S.COL C2520C-3R3G-A T 179.2/88.5
L4 6200010830 S.COL C2520C-3R3G-A T 179.2/80.2
L5 6200010830 S.COL C2520C-3R3G-A T 178.2/84.3
