5 - 56
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[DC-DC UNIT]
R81 7030006091 S.RES ERA3YED 822V (8.2 k) T 27/12.2
R101 7030009851 S.RES ERA3YED 271V (270) T 102/17.9
R102 7030007230 S.RES ERA3YED 102V (1 k) T 102/20.8
R103 7030006091 S.RES ERA3YED 822V (8.2 k) T 97.9/15.7
R121 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 133.3/72.6
R122 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 132/71.8
R141 7030008190 S.RES ERJ12YJ330U (33) T 14.7/99
C9 4510008910 S.ELE EEEFC1C101P T 138.5/69.7
C21 4030011600 S.CER C1608 JB 1E 104K-T T 125.3/40.8
C22 4510008610 S.ELE 10SVP150MX T 131.1/38.1
C23 4030011340 S.CER C1608 CH 1H 471J-T T 119.1/17.1
C24 4030004750 S.CER C2012 JB 1H 103K-T T 119.7/23.7
C25 4030005110 S.CER C2012 JB 1E 473K-T T 125.3/27.5
C26 4550006770 S.TAN TEESVD2 1C 476M-12R T 132.1/30
C27 4510008610 S.ELE 10SVP150MX T 115.3/47.4
C41 4030011600 S.CER C1608 JB 1E 104K-T T 77.5/89.5
C42 4510008610 S.ELE 10SVP150MX T 80.8/95.2
C43 4030011340 S.CER C1608 CH 1H 471J-T T 101.4/83.8
C44 4030004750 S.CER C2012 JB 1H 103K-T T 94.8/84.1
C45 4030005110 S.CER C2012 JB 1E 473K-T T 91.4/90.6
C46 4550007140 S.TAN TEESVD 1C 107M12R T 87.6/96.4
C47 4510008610 S.ELE 10SVP150MX T 70.5/79.1
C61 4030011600 S.CER C1608 JB 1E 104K-T T 81.5/56
C62 4510008610 S.ELE 10SVP150MX T 77.3/60.9
C63 4030011340 S.CER C1608 CH 1H 471J-T T 101.4/48.5
C64 4030004750 S.CER C2012 JB 1H 103K-T T 94.8/49.1
C65 4030011600 S.CER C1608 JB 1E 104K-T T 91.1/55.4
C66 4550006770 S.TAN TEESVD2 1C 476M-12R T 85.6/61.7
C67 4510008610 S.ELE 10SVP150MX T 69.6/44
C81 4030011600 S.CER C1608 JB 1E 104K-T T 33.1/28.4
C82 4510008610 S.ELE 10SVP150MX T 37.9/32.4
C83 4030011340 S.CER C1608 CH 1H 471J-T T 26.9/9.7
C84 4030004750 S.CER C2012 JB 1H 103K-T T 27.7/16.1
C85 4030011600 S.CER C1608 JB 1E 104K-T T 33.4/19.8
C86 4550006770 S.TAN TEESVD2 1C 476M-12R T 38/25.1
C87 4510008610 S.ELE 10SVP150MX T 21.7/42.7
C101 4030011600 S.CER C1608 JB 1E 104K-T T 80.1/22.7
C102 4510008610 S.ELE 10SVP150MX T 75.7/27.3
C103 4030011340 S.CER C1608 CH 1H 471J-T T 100.4/15.6
C104 4030004750 S.CER C2012 JB 1H 103K-T T 93.8/16.2
C105 4030005110 S.CER C2012 JB 1E 473K-T T 90.1/22.5
C106 4550006770 S.TAN TEESVD2 1C 476M-12R T 83.8/28.2
C107 4510008610 S.ELE 10SVP150MX T 68.6/11.3
C122 4030011600 S.CER C1608 JB 1E 104K-T T 132/69.2
C123 4510008940 S.ELE EEEFC1V470P T 131.7/79.3
C124 4030006880 S.CER C1608 JB 1H 472K-T T 120.8/95.1
C141 4030011600 S.CER C1608 JB 1E 104K-T T 7.6/97.9
RL142 6330001760 RLY AW3023
J2 6510003470 CNR B11B-EH-S
J3 6510003430 CNR B07B-EH-S
J4 6510003460 CNR B10B-EH-S
J5 6510020421 S.CNR S4B-PH-SM4-TB (LF) (SN) T 128.2/97.5
W1 8900012780 CBL OPC-1298
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[TUNER UNIT]
MF1 2710000780 MTR MP24Z
MF2 2710000780 MTR MP24Z
MF3 2710000470 FAN MF60B-12H901
W1 8900012900 CBL OPC-1345
W2 8900012900 CBL OPC-1345
W3 8900009410 CBL OPC-927 (P=1, N=24, L=100)
W51 9025900490 WIR 23/00/230/B11/B09
IC1 1140004120 S.IC M38022M2-138FP T 65.7/81.8
IC2 1130010390 S.IC HN58X2416TI T 54/86.9
IC3 1130003921 S.IC TC4S69F (TE85R,F) T 55.9/58.2
IC4 1180001071 S.IC TA7805F (TE16L,Q) B 63/57.7
IC5 1130009691 S.IC TC74HCT7007AF (F) B 92.5/91.6
IC6 1130006441 S.IC TC7S08F (TE85R,F) T 81.7/70.3
IC51 1130011530 S.IC CD74HC4094M96 T 42.2/72.4
IC52 1130007690 S.IC BU4066BCF-E2 B 12.5/76.8
IC55 1130011530 S.IC CD74HC4094M96 B 100.2/76.1
IC56 1130011530 S.IC CD74HC4094M96 B 114.3/76.1
IC57 1160000131 S.IC TD62783AFG (S.EL) T 99.6/73.1
IC58 1160000131 S.IC TD62783AFG (S.EL) T 113.7/73.1
IC101 1110000960 S.IC NJM4558M-TE1 T 19.4/37.8
IC151 1120002301 S.IC TC74AC04F (F) B 35.3/44.3
IC153 1130012011 S.IC TC7SZ32F (TE85L,F) T 31.2/47.3
IC154 1130012011 S.IC TC7SZ32F (TE85L,F) T 42.4/45.8
IC155 1130012011 S.IC TC7SZ32F (TE85L,F) T 36/47.5
IC156 1130012020 S.IC TC74ACT112F (EL) T 38.4/56.5
IC201 1110000960 S.IC NJM4558M-TE1 T 19/54.7
IC301 1110002690 S.IC NJM2903M-TE1 T 73.4/59
IC401 1160000131 S.IC TD62783AFG (S.EL) T 13.6/86.1
IC402 1160000131 S.IC TD62783AFG (S.EL) T 31.6/84.7
Q1 1590001330 S.TR DTA114EUA T106 T 78.5/75.2
Q2 1590000680 S.TR DTC114EUA T106 T 77.8/71.2
Q3 1590000680 S.TR DTC114EUA T106 T 128.4/74.5
Q4 1590000680 S.TR DTC114EUA T106 T 128.4/77
Q5 1590000680 S.TR DTC114EUA T106 T 128.4/81.3
Q6 1590000680 S.TR DTC114EUA T106 T 128.4/83.8
Q7 1590000680 S.TR DTC114EUA T106 T 128.4/88.5
Q8 1590000680 S.TR DTC114EUA T106 T 128.4/91
Q9 1590000680 S.TR DTC114EUA T106 T 128.4/95.7
Q10 1590000680 S.TR DTC114EUA T106 T 128.4/100.5
Q11 1590000680 S.TR DTC114EUA T106 B 85.7/99.8
Q51 1590000680 S.TR DTC114EUA T106 T 6.1/78.6
Q52 1590000680 S.TR DTC114EUA T106 T 12.5/78.6
Q53 1590000680 S.TR DTC114EUA T106 B 6.6/72.8
Q54 1560001260 S.FET 2SK3018 T106 B 121.2/80.2
Q55 1590000680 S.TR DTC114EUA T106 B 130.2/68.9
Q59 1590000680 S.TR DTC114EUA T106 T 56.8/69.5
Q201 1560000871 S.FET 2SK515-T1B-A (X33) T 52.6/43
Q251 1590000680 S.TR DTC114EUA T106 T 74.2/34.9
D1 1730000411 S.ZEN RD5.1M-T2B-A B2 T 63.4/58.4
D2 1710000780 S.DIO MA114 (TX) T 67.7/55.9
D3 1750000201 S.DIO 1SS319 (TE85R,F) B 129.5/98.1
D4 1750000201 S.DIO 1SS319 (TE85R,F) B 129.5/90
D5 1750000201 S.DIO 1SS319 (TE85R,F) B 129.5/82.8
D6 1750000201 S.DIO 1SS319 (TE85R,F) B 129.5/76
D7 1730000031 S.ZEN RD5.6M-T2B-A B2 T 63.6/54.9
D101 1790000491 S.DIO HSM88ASTR-E T 14.7/24.3
D102 1790000491 S.DIO HSM88ASTR-E T 25.6/29.5
D103 1750000201 S.DIO 1SS319 (TE85R,F) T 19.3/42.1
D151 1790000491 S.DIO HSM88ASTR-E T 32/38.2
D152 1790000491 S.DIO HSM88ASTR-E T 39.4/38.2
D153 1790000491 S.DIO HSM88ASTR-E T 28.4/57.2
D154 1790000491 S.DIO HSM88ASTR-E T 29.6/53.4
D201 1790000491 S.DIO HSM88ASTR-E T 57.6/37.2
D202 1790000491 S.DIO HSM88ASTR-E T 48.5/37.1
D203 1750000201 S.DIO 1SS319 (TE85R,F) T 18/60.9
D251 1750000271 S.DIO 1SS301 (TE85R,F) T 72.1/36.5
D301 1790000491 S.DIO HSM88ASTR-E T 81.5/58.3
D302 1790000491 S.DIO HSM88ASTR-E T 88.4/59.6
X1 6050009890 S.XTL CR-569 (6.144 MHz) T 83.2/79.5
L1 6200003261 S.COL NLV32T-101J T 51.1/76.5
L2 6200003261 S.COL NLV32T-101J T 54.5/77.8
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[CTRL BOARD]
