5 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[VR-D BOARD]
R1 7210001130 VAR RK097111T005A (10KB)
R2 7210001130 VAR RK097111T005A (10KB)
R3 7210001130 VAR RK097111T005A (10KB)
R4 7210001130 VAR RK097111T005A (10KB)
R5 7210001130 VAR RK097111T005A (10KB)
R6 7210001130 VAR RK097111T005A (10KB)
R7 7210001130 VAR RK097111T005A (10KB)
R11 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 11.3/3.6
R12 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 28.4/3.6
R13 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 45.2/3.6
R14 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 62.3/3.6
R15 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 79.2/3.6
R16 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 96.3/3.6
R17 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 100.5/6.5
C11 4030006880 S.CER C1608 JB 1H 472K-T B 11.3/2
C12 4030006880 S.CER C1608 JB 1H 472K-T B 28.4/2
C13 4030006880 S.CER C1608 JB 1H 472K-T B 45.2/2
C14 4030006880 S.CER C1608 JB 1H 472K-T B 62.3/2
C15 4030006880 S.CER C1608 JB 1H 472K-T B 79.2/2
C16 4030006880 S.CER C1608 JB 1H 472K-T B 96.3/2
C17 4030006880 S.CER C1608 JB 1H 472K-T B 100.5/4.9
J1 6510019971 S.CNR 52808-1071 B 43/16
R2 7030003400 S.RES ERJ3GEYJ 471 V (470) B 8.3/85.5
R3 7030003420 S.RES ERJ3GEYJ 681 V (680) B 8.3/53.1
R4 7030003400 S.RES ERJ3GEYJ 471 V (470) B 8.3/56.1
R6 7030003400 S.RES ERJ3GEYJ 471 V (470) B 26.8/42.4
R7 7030003400 S.RES ERJ3GEYJ 471 V (470) B 33/41.6
R8 7030003400 S.RES ERJ3GEYJ 471 V (470) B 51.6/40.4
R9 7030003400 S.RES ERJ3GEYJ 471 V (470) B 62.5/36
R10 7030003400 S.RES ERJ3GEYJ 471 V (470) B 75.6/36
R11 7030003400 S.RES ERJ3GEYJ 471 V (470) B 90/37.5
R12 7030003400 S.RES ERJ3GEYJ 471 V (470) B 57.8/82.8
R13 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 3.6/40.8
R14 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 48.4/80.4
R15 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 29.6/39.4
R16 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 41.1/39.4
R17 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 66.3/36
R18 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 79.5/38.1
R19 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 57.3/40.5
R20 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 29.6/40.7
R21 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 2.4/38.1
R22 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 100.2/66.5
R23 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 101.5/63.3
R24 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 98.6/41.5
R25 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 100.3/19.2
R26 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 100.3/7.2
R27 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 98.6/77.5
R28 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 96.2/35.2
R29 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 51.2/53.1
R30 7030003400 S.RES ERJ3GEYJ 471 V (470) B 47/58
C1 4030011600 S.CER C1608 JB 1E 104K-T B 99.2/63
C2 4030011600 S.CER C1608 JB 1E 104K-T B 88.8/59.1
C3 4030011600 S.CER C1608 JB 1E 104K-T B 99.4/60.4
C4 4030011600 S.CER C1608 JB 1E 104K-T B 90.1/59.1
C5 4030011600 S.CER C1608 JB 1E 104K-T B 98.9/59
C6 4030011600 S.CER C1608 JB 1E 104K-T B 53.3/77.2
C7 4030011600 S.CER C1608 JB 1E 104K-T B 84.8/80.1
C8 4030011600 S.CER C1608 JB 1E 104K-T B 83.5/65.3
C9 4030011600 S.CER C1608 JB 1E 104K-T B 88/52.2
J1 6510019971 S.CNR 52808-1071 B 46.7/72.7
J2 6510019971 S.CNR 52808-1071 B 83.7/72.7
J3 6510022470 S.CNR 40FLT-SM1-TB B 94.3/58.7
DS5 5040002980 S.LED SML-512DW-T86 T 8.5/87.6
DS6 5040002930 S.LED SML-512MW T86 T 8.5/86.3
DS7 5040002930 S.LED SML-512MW T86 T 8.5/41.4
DS8 5040002930 S.LED SML-512MW T86 T 26.2/43
DS9 5040002930 S.LED SML-512MW T86 T 37.7/43
DS10 5040002930 S.LED SML-512MW T86 T 49.2/43
DS11 5040002930 S.LED SML-512MW T86 T 63.2/43
DS12 5040002930 S.LED SML-512MW T86 T 56.2/84.4
DS13 5040002930 S.LED SML-512MW T86 T 74.7/43
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[SW-A BOARD]
DS14 5040002930 S.LED SML-512MW T86 T 86.2/43
DS15 5040002990 S.LED SML-512UWT86 T 8.5/56.4
DS16 5040002930 S.LED SML-512MW T86 T 8.5/55.1
DS17 5040002930 S.LED SML-512MW T86 T 56.2/56.4
S1 2260002740 S.SW LS8J2M-T T 9.7/77.2
S2 2260002740 S.SW LS8J2M-T T 8.2/62.5
S3 2260002740 S.SW LS8J2M-T T 8.2/48.8
S4 2260002740 S.SW LS8J2M-T T 8.2/35.1
S5 2260002740 S.SW LS8J2M-T T 37.5/38.9
S6 2260002740 S.SW LS8J2M-T T 26/38.9
S7 2260002740 S.SW LS8J2M-T T 49/38.9
S8 2260002740 S.SW LS8J2M-T T 63/38.9
S11 2260002740 S.SW LS8J2M-T T 56/79
S12 2260002740 S.SW LS8J2M-T T 74.5/38.9
S13 2260002740 S.SW LS8J2M-T T 86/38.9
S14 2260002740 S.SW LS8J2M-T T 100.3/82.7
S15 2260002740 S.SW LS8J2M-T T 100.3/70.7
S16 2260002740 S.SW LS8J2M-T T 100.3/58.7
S17 2260002740 S.SW LS8J2M-T T 100.3/46.7
S18 2260002740 S.SW LS8J2M-T T 100.3/34.7
S19 2260002740 S.SW LS8J2M-T T 100.3/22.7
S20 2260002740 S.SW LS8J2M-T T 100.3/10.7
S21 2260002740 S.SW LS8J2M-T T 56/51
J1 6510020531 S.CNR 52808-1871 B 112/20.3
S1 2260002740 S.SW LS8J2M-T T 16.8/24.6
S2 2260002740 S.SW LS8J2M-T T 38.8/24.6
S3 2260002740 S.SW LS8J2M-T T 60.8/24.6
S4 2260002740 S.SW LS8J2M-T T 82.8/24.6
S5 2260002740 S.SW LS8J2M-T T 104.8/24.6
S6 2260002740 S.SW LS8J2M-T T 126.8/24.6
S7 2260002740 S.SW LS8J2M-T T 148.8/24.6
S8 2260002740 S.SW LS8J2M-T T 16.8/15.2
S9 2260002740 S.SW LS8J2M-T T 38.8/15.2
S10 2260002740 S.SW LS8J2M-T T 60.8/15.2
S11 2260002740 S.SW LS8J2M-T T 82.8/15.2
S12 2260002740 S.SW LS8J2M-T T 104.8/15.2
S13 2260002740 S.SW LS8J2M-T T 126.8/15.2
S14 2260002740 S.SW LS8J2M-T T 148.8/15.2
S15 2260002740 S.SW LS8J2M-T T 125.5/3.1
S16 2260002740 S.SW LS8J2M-T T 145.2/3.1
S17 2260002740 S.SW LS8J2M-T T 167.3/3.1
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[SW-A BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[SW-B BOARD]
