5 - 51
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]
R1013 7030003200 S.RES ERJ3GEYJ 100 V (10) B 231.3/57.5
R1014 7030003200 S.RES ERJ3GEYJ 100 V (10) B 222.7/58.5
R1015 7030003200 S.RES ERJ3GEYJ 100 V (10) B 231.3/59.5
R1016 7030003200 S.RES ERJ3GEYJ 100 V (10) T 181/22.1
R1017 7030003200 S.RES ERJ3GEYJ 100 V (10) T 179.7/22.1
R1018 7030003200 S.RES ERJ3GEYJ 100 V (10) T 176.7/22.1
R1019 7030003200 S.RES ERJ3GEYJ 100 V (10) T 174.7/22.2
R1020 7030003200 S.RES ERJ3GEYJ 100 V (10) T 173.4/22.2
R1021 7030003200 S.RES ERJ3GEYJ 100 V (10) T 172.1/22.2
R1022 7030003200 S.RES ERJ3GEYJ 100 V (10) T 170.8/22.2
R1023 7030003200 S.RES ERJ3GEYJ 100 V (10) T 169.5/22.2
R1024 7030003200 S.RES ERJ3GEYJ 100 V (10) B 220.7/85
R1025 7030003320 S.RES ERJ3GEYJ 101 V (100) B 120.5/9.7
R1026 7030003320 S.RES ERJ3GEYJ 101 V (100) B 108.9/8.1
R1027 7030003320 S.RES ERJ3GEYJ 101 V (100) B 137.3/17.2
R1028 7030003320 S.RES ERJ3GEYJ 101 V (100) B 135.6/7.2
R1029 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 120.5/11
R1030 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 120.5/7.1
R1031 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 108.9/12
R1032 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 108.9/9.4
R1033 7030003860 S.RES ERJ3GE JPW V T 188.9/62.5
R1035 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 192.2/60.1
R1036 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 184.5/64.7
R1041 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 173.8/28.2
R1042 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k) T 115.2/16.6
R1052 7030008240 S.RES ERJ12YJ0R00U T 86.1/114.3
R1053 7030008240 S.RES ERJ12YJ0R00U T 67.5/114.4
R1054 7030008240 S.RES ERJ12YJ0R00U T 9.4/116.7
R1056 7030003860 S.RES ERJ3GE JPW V T 138.7/40.3
R1057 7030003860 S.RES ERJ3GE JPW V B 123.1/7.1
R1101 7030003280 S.RES ERJ3GEYJ 470 V (47) T 18.7/30.5
R1102 7030003280 S.RES ERJ3GEYJ 470 V (47) T 18.7/33.1
R1103 7030003280 S.RES ERJ3GEYJ 470 V (47) T 18.7/35.7
R1104 7030003280 S.RES ERJ3GEYJ 470 V (47) T 20.5/30.5
R1105 7030003280 S.RES ERJ3GEYJ 470 V (47) T 20.5/33.1
R1106 7030003280 S.RES ERJ3GEYJ 470 V (47) T 20.5/35.7
R1107 7030003280 S.RES ERJ3GEYJ 470 V (47) T 22.3/30.5
R1108 7030003280 S.RES ERJ3GEYJ 470 V (47) T 22.3/33.1
R1109 7030003280 S.RES ERJ3GEYJ 470 V (47) T 22.3/35.7
R1110 7030003280 S.RES ERJ3GEYJ 470 V (47) T 24.1/27.9
R1111 7030003280 S.RES ERJ3GEYJ 470 V (47) T 24.1/30.5
R1112 7030003280 S.RES ERJ3GEYJ 470 V (47) T 24.1/33.1
R1113 7030003280 S.RES ERJ3GEYJ 470 V (47) T 25.9/27.9
R1114 7030003280 S.RES ERJ3GEYJ 470 V (47) T 25.9/30.5
R1115 7030003280 S.RES ERJ3GEYJ 470 V (47) T 25.9/33.1
R1116 7030003280 S.RES ERJ3GEYJ 470 V (47) T 27.3/30.5
R1117 7030003280 S.RES ERJ3GEYJ 470 V (47) T 28.6/30.5
R1118 7030003280 S.RES ERJ3GEYJ 470 V (47) T 29.9/30.5
R1119 7030003280 S.RES ERJ3GEYJ 470 V (47) T 31.2/30.5
R1120 7030003280 S.RES ERJ3GEYJ 470 V (47) T 32.5/30.5
R1121 7030003280 S.RES ERJ3GEYJ 470 V (47) T 33.8/30.5
R1122 7030003280 S.RES ERJ3GEYJ 470 V (47) T 35.1/30.5
R1123 7030003280 S.RES ERJ3GEYJ 470 V (47) T 40.5/29.6
R1124 7030003280 S.RES ERJ3GEYJ 470 V (47) T 42.8/34.8
R1125 7030003280 S.RES ERJ3GEYJ 470 V (47) T 43.5/32.2
R1126 7030003280 S.RES ERJ3GEYJ 470 V (47) T 44.2/34.8
R1127 7030003280 S.RES ERJ3GEYJ 470 V (47) T 44.9/32.2
R1128 7030003280 S.RES ERJ3GEYJ 470 V (47) T 45.6/34.8
R1129 7030003280 S.RES ERJ3GEYJ 470 V (47) T 46.3/32.2
R1130 7030003280 S.RES ERJ3GEYJ 470 V (47) T 47/34.8
R1131 7030003280 S.RES ERJ3GEYJ 470 V (47) T 47.7/32.2
R1132 7030003280 S.RES ERJ3GEYJ 470 V (47) T 48.4/34.8
R1133 7030003280 S.RES ERJ3GEYJ 470 V (47) T 49.1/32.2
R1134 7030003280 S.RES ERJ3GEYJ 470 V (47) T 49.8/34.8
R1135 7030003280 S.RES ERJ3GEYJ 470 V (47) T 50.5/32.2
R1136 7030003280 S.RES ERJ3GEYJ 470 V (47) T 51.2/34.8
R1137 7030003280 S.RES ERJ3GEYJ 470 V (47) T 51.9/32.2
R1138 7030003280 S.RES ERJ3GEYJ 470 V (47) T 52.6/34.8
R1139 7030003280 S.RES ERJ3GEYJ 470 V (47) T 53.3/32.2
R1140 7030003280 S.RES ERJ3GEYJ 470 V (47) T 54/34.8
R1141 7030003280 S.RES ERJ3GEYJ 470 V (47) T 54.7/32.2
R1142 7030003280 S.RES ERJ3GEYJ 470 V (47) T 55.4/34.8
R1143 7030003280 S.RES ERJ3GEYJ 470 V (47) T 56.1/32.2
R1144 7030003280 S.RES ERJ3GEYJ 470 V (47) T 56.8/34.8
R1145 7030003280 S.RES ERJ3GEYJ 470 V (47) T 57.5/32.2
R1146 7030003280 S.RES ERJ3GEYJ 470 V (47) T 58.2/34.8
R1151 7030003290 S.RES ERJ3GEYJ 560 V (56) T 205.2/11.7
R1152 7030003320 S.RES ERJ3GEYJ 101 V (100) T 203.6/11.7
R1153 7030003320 S.RES ERJ3GEYJ 101 V (100) T 200.8/13.2
R1154 7030003320 S.RES ERJ3GEYJ 101 V (100) T 199.5/13.2
R1155 7030003320 S.RES ERJ3GEYJ 101 V (100) B 201.4/10.8
R1156 7030003320 S.RES ERJ3GEYJ 101 V (100) T 198.2/13.2
R1157 7030003320 S.RES ERJ3GEYJ 101 V (100) B 200.1/10.8
R1158 7030003320 S.RES ERJ3GEYJ 101 V (100) T 196.9/13.2
R1159 7030003320 S.RES ERJ3GEYJ 101 V (100) B 198.8/10.8
R1160 7030003320 S.RES ERJ3GEYJ 101 V (100) T 195.6/13.2
R1161 7030003320 S.RES ERJ3GEYJ 101 V (100) B 197.5/10.8
R1162 7030003320 S.RES ERJ3GEYJ 101 V (100) B 196.2/10.8
R1163 7030003320 S.RES ERJ3GEYJ 101 V (100) T 194.3/13.2
R1164 7030003320 S.RES ERJ3GEYJ 101 V (100) T 193/13.2
R1165 7030003320 S.RES ERJ3GEYJ 101 V (100) T 191.1/14.9
R1166 7030003320 S.RES ERJ3GEYJ 101 V (100) T 189.8/14.9
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]
R1167 7030003320 S.RES ERJ3GEYJ 101 V (100) T 188.5/14.9
R1168 7030003320 S.RES ERJ3GEYJ 101 V (100) T 187.2/14.9
R1169 7030003320 S.RES ERJ3GEYJ 101 V (100) T 185.9/14.9
R1170 7030003320 S.RES ERJ3GEYJ 101 V (100) T 181.4/9.5
C1 4030011600 S.CER C1608 JB 1E 104K-T B 69.7/83.3
C2 4030011600 S.CER C1608 JB 1E 104K-T B 68.1/83.3
C3 4030011600 S.CER C1608 JB 1E 104K-T B 63.3/83.3
C4 4030011600 S.CER C1608 JB 1E 104K-T B 59.3/83.3
C5 4030011600 S.CER C1608 JB 1E 104K-T B 48.9/83.3
C6 4030011600 S.CER C1608 JB 1E 104K-T B 66.9/100.4
C7 4030011600 S.CER C1608 JB 1E 104K-T B 62.1/100.4
C8 4030011600 S.CER C1608 JB 1E 104K-T T 69.7/107.5
C9 4030011600 S.CER C1608 JB 1E 104K-T T 68.1/107.5
C10 4030011600 S.CER C1608 JB 1E 104K-T T 63.3/107.5
C11 4030011600 S.CER C1608 JB 1E 104K-T T 59.3/107.5
C12 4030011600 S.CER C1608 JB 1E 104K-T T 48.9/107.5
C13 4030011600 S.CER C1608 JB 1E 104K-T T 66.6/90.9
C14 4030011600 S.CER C1608 JB 1E 104K-T T 61.9/90.9
C51 4030011600 S.CER C1608 JB 1E 104K-T B 105.5/54.7
C52 4030011600 S.CER C1608 JB 1E 104K-T B 97.1/46.1
C53 4030011600 S.CER C1608 JB 1E 104K-T B 94.4/46.1
C54 4030011600 S.CER C1608 JB 1E 104K-T B 106.6/51
C55 4030011600 S.CER C1608 JB 1E 104K-T B 109/65.9
C56 4030011600 S.CER C1608 JB 1E 104K-T B 114/65.9
C57 4030011600 S.CER C1608 JB 1E 104K-T B 127.6/63.1
C58 4030011600 S.CER C1608 JB 1E 104K-T B 127.7/55.9
C59 4030011600 S.CER C1608 JB 1E 104K-T B 117.5/46.1
C60 4030011600 S.CER C1608 JB 1E 104K-T B 111.5/46.1
C61 4030009990 S.CER C1608 CH 1H 200J-T T 143/78.1
C62 4030011600 S.CER C1608 JB 1E 104K-T T 139.9/100.6
C63 4030008890 S.CER C1608 JB 1H 273K-T T 144.5/100.6
C64 4030011600 S.CER C1608 JB 1E 104K-T T 146.7/102.5
C65 4030011600 S.CER C1608 JB 1E 104K-T T 96/34.2
C66 4030011600 S.CER C1608 JB 1E 104K-T B 34.1/27.4
C101 4030011600 S.CER C1608 JB 1E 104K-T T 23.3/71.9
C102 4030011600 S.CER C1608 JB 1E 104K-T B 43.2/48.2
C103 4030011600 S.CER C1608 JB 1E 104K-T B 47.1/78
C104 4030011600 S.CER C1608 JB 1E 104K-T B 46.8/58.8
C105 4030011600 S.CER C1608 JB 1E 104K-T B 49.5/71
C106 4030011600 S.CER C1608 JB 1E 104K-T B 46.8/57.5
C107 4030011600 S.CER C1608 JB 1E 104K-T B 52/57.5
C108 4030011600 S.CER C1608 JB 1E 104K-T B 57.7/57.5
C109 4030011600 S.CER C1608 JB 1E 104K-T B 59.6/60.8
C110 4030011600 S.CER C1608 JB 1E 104K-T B 46.8/68
C111 4550007520 S.TAN F931A106MAABMA B 57.7/48.8
C112 4030011600 S.CER C1608 JB 1E 104K-T B 59/50.5
C113 4550007520 S.TAN F931A106MAABMA B 63.6/48.8
C114 4030011600 S.CER C1608 JB 1E 104K-T B 62/50.5
C115 4550007520 S.TAN F931A106MAABMA B 68.8/48.8
C116 4030011600 S.CER C1608 JB 1E 104K-T B 64.9/50.5
C117 4030011600 S.CER C1608 JB 1E 104K-T B 46.9/71
C118 4030011600 S.CER C1608 JB 1E 104K-T B 46.8/61.4
C119 4030011600 S.CER C1608 JB 1E 104K-T B 46.8/69.3
C120 4030011600 S.CER C1608 JB 1E 104K-T B 59.6/69.4
C121 4030011600 S.CER C1608 JB 1E 104K-T B 57.8/70.2
C122 4030011600 S.CER C1608 JB 1E 104K-T B 56.5/70.2
C123 4030006860 S.CER C1608 JB 1H 102K-T B 57.3/78
C124 4030011600 S.CER C1608 JB 1E 104K-T B 52.1/71
C125 4030011600 S.CER C1608 JB 1E 104K-T B 54.7/71
C126 4030011600 S.CER C1608 JB 1E 104K-T B 46.8/66.7
C127 4030011600 S.CER C1608 JB 1E 104K-T B 43.2/50.8
C128 4030011600 S.CER C1608 JB 1E 104K-T B 52.2/50.8
C129 4030011600 S.CER C1608 JB 1E 104K-T B 46.1/64.8
C130 4030011600 S.CER C1608 JB 1E 104K-T B 59.6/66.8
C131 4030011600 S.CER C1608 JB 1E 104K-T B 66.4/68.7
C132 4030011600 S.CER C1608 JB 1E 104K-T B 59.6/63.6
C133 4030011600 S.CER C1608 JB 1E 104K-T B 47.1/50.9
C134 4030011600 S.CER C1608 JB 1E 104K-T B 39.3/58.6
C135 4030011600 S.CER C1608 JB 1E 104K-T B 46.8/60.1
C136 4030011600 S.CER C1608 JB 1E 104K-T B 54.6/57.5
C137 4030011600 S.CER C1608 JB 1E 104K-T B 49.4/57.5
C138 4030011600 S.CER C1608 JB 1E 104K-T B 54.7/69.3
C139 4030011600 S.CER C1608 JB 1E 104K-T B 59.6/58.2
C140 4030006900 S.CER C1608 JB 1H 103K-T B 66.4/58.5
C141 4030011600 S.CER C1608 JB 1E 104K-T T 64.3/38.6
C142 4030011600 S.CER C1608 JB 1E 104K-T T 76.8/32.5
C144 4030011600 S.CER C1608 JB 1E 104K-T T 7.9/62.8
C145 4030011600 S.CER C1608 JB 1E 104K-T T 10/62.1
C146 4030007020 S.CER C1608 CH 1H 120J-T T 8.1/58.8
C147 4030007020 S.CER C1608 CH 1H 120J-T T 10/59.5
C148 4030011600 S.CER C1608 JB 1E 104K-T T 6.7/70.5
C149 4030011600 S.CER C1608 JB 1E 104K-T T 7.4/73.7
C201 4030011600 S.CER C1608 JB 1E 104K-T B 118.1/103.3
C202 4030011600 S.CER C1608 JB 1E 104K-T B 120.7/103.3
C203 4030011600 S.CER C1608 JB 1E 104K-T B 124.2/103.3
C204 4030011600 S.CER C1608 JB 1E 104K-T B 127.3/103.3
C205 4030011600 S.CER C1608 JB 1E 104K-T B 137.4/103.5
C206 4030011600 S.CER C1608 JB 1E 104K-T B 120.7/87.6
C207 4030011600 S.CER C1608 JB 1E 104K-T B 125.5/87.7
C208 4030011600 S.CER C1608 JB 1E 104K-T B 117.7/85.8
