Feb. 2009
2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[SW-A BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R2 7030003400 S.RES ERJ3GEYJ 471 V (470) B 8.3/85.5
R3 7030003420 S.RES ERJ3GEYJ 681 V (680) B 8.3/53.1
R4 7030003400 S.RES ERJ3GEYJ 471 V (470) B 8.3/56.1
R6 7030003400 S.RES ERJ3GEYJ 471 V (470) B 26.8/42.4
R7 7030003400 S.RES ERJ3GEYJ 471 V (470) B 33/41.6
R8 7030003400 S.RES ERJ3GEYJ 471 V (470) B 51.6/40.4
R9 7030003400 S.RES ERJ3GEYJ 471 V (470) B 62.5/36
R10 7030003400 S.RES ERJ3GEYJ 471 V (470) B 75.6/36
R11 7030003400 S.RES ERJ3GEYJ 471 V (470) B 90/37.5
R12 7030003400 S.RES ERJ3GEYJ 471 V (470) B 57.8/82.8
R13 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 3.6/40.8
R14 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 48.4/80.4
R15 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 29.6/39.4
R16 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 41.1/39.4
R17 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 66.3/36
R18 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 79.5/38.1
R19 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 57.3/40.5
R20 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 29.6/40.7
R21 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 2.4/38.1
R22 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 100.2/66.5
R23 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 101.5/63.3
R24 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 98.6/41.5
R25 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 100.3/19.2
R26 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 100.3/7.2
R27 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 98.6/77.5
R28 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 96.2/35.2
R29 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 51.2/53.1
R30 7030003400 S.RES ERJ3GEYJ 471 V (470) B 47/58
C1 4030011600 S.CER C1608 JB 1E 104K-T B 99.2/63
C2 4030011600 S.CER C1608 JB 1E 104K-T B 88.8/59.1
C3 4030011600 S.CER C1608 JB 1E 104K-T B 99.4/60.4
C4 4030011600 S.CER C1608 JB 1E 104K-T B 90.1/59.1
C5 4030011600 S.CER C1608 JB 1E 104K-T B 98.9/59
C6 4030011600 S.CER C1608 JB 1E 104K-T B 53.3/77.2
C7 4030011600 S.CER C1608 JB 1E 104K-T B 84.8/80.1
C8 4030011600 S.CER C1608 JB 1E 104K-T B 83.5/65.3
C9 4030011600 S.CER C1608 JB 1E 104K-T B 88/52.2
J1 6510019971 S.CNR 52808-1071 B 46.7/72.7
J2 6510019971 S.CNR 52808-1071 B 83.7/72.7
J3 6510022471 S.CNR 40FLT-SM2-TB (LF) (SN) B 94.3/58.7
DS5 5040002980 S.LED SML-512DW-T86 T 8.5/87.6
DS6 5040002930 S.LED SML-512MW T86 T 8.5/86.3
DS7 5040002930 S.LED SML-512MW T86 T 8.5/41.4
DS8 5040002930 S.LED SML-512MW T86 T 26.2/43
DS9 5040002930 S.LED SML-512MW T86 T 37.7/43
DS10 5040002930 S.LED SML-512MW T86 T 49.2/43
DS11 5040002930 S.LED SML-512MW T86 T 63.2/43
DS12 5040002930 S.LED SML-512MW T86 T 56.2/84.4
DS13 5040002930 S.LED SML-512MW T86 T 74.7/43
DS14 5040002930 S.LED SML-512MW T86 T 86.2/43
DS15 5040002990 S.LED SML-512UWT86 T 8.5/56.4
DS16 5040002930 S.LED SML-512MW T86 T 8.5/55.1
DS17 5040002930 S.LED SML-512MW T86 T 56.2/56.4
S1 2260002740 S.SW LS8J2M-T T 9.7/77.2
S2 2260002740 S.SW LS8J2M-T T 8.2/62.5
S3 2260002740 S.SW LS8J2M-T T 8.2/48.8
S4 2260002740 S.SW LS8J2M-T T 8.2/35.1
S5 2260002740 S.SW LS8J2M-T T 37.5/38.9
S6 2260002740 S.SW LS8J2M-T T 26/38.9
S7 2260002740 S.SW LS8J2M-T T 49/38.9
S8 2260002740 S.SW LS8J2M-T T 63/38.9
S11 2260002740 S.SW LS8J2M-T T 56/79
S12 2260002740 S.SW LS8J2M-T T 74.5/38.9
S13 2260002740 S.SW LS8J2M-T T 86/38.9
S14 2260002740 S.SW LS8J2M-T T 100.3/82.7
S15 2260002740 S.SW LS8J2M-T T 100.3/70.7
S16 2260002740 S.SW LS8J2M-T T 100.3/58.7
S17 2260002740 S.SW LS8J2M-T T 100.3/46.7
S18 2260002740 S.SW LS8J2M-T T 100.3/34.7
S19 2260002740 S.SW LS8J2M-T T 100.3/22.7
S20 2260002740 S.SW LS8J2M-T T 100.3/10.7
S21 2260002740 S.SW LS8J2M-T T 56/51
S.=Surface mount
[SW-B BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
J1 6510020531 S.CNR 52808-1871 B 112/20.3
S1 2260002740 S.SW LS8J2M-T T 16.8/24.6
S2 2260002740 S.SW LS8J2M-T T 38.8/24.6
S3 2260002740 S.SW LS8J2M-T T 60.8/24.6
S4 2260002740 S.SW LS8J2M-T T 82.8/24.6
S5 2260002740 S.SW LS8J2M-T T 104.8/24.6
S6 2260002740 S.SW LS8J2M-T T 126.8/24.6
S7 2260002740 S.SW LS8J2M-T T 148.8/24.6
S8 2260002740 S.SW LS8J2M-T T 16.8/15.2
S9 2260002740 S.SW LS8J2M-T T 38.8/15.2
S10 2260002740 S.SW LS8J2M-T T 60.8/15.2
S11 2260002740 S.SW LS8J2M-T T 82.8/15.2
S12 2260002740 S.SW LS8J2M-T T 104.8/15.2
S13 2260002740 S.SW LS8J2M-T T 126.8/15.2
S14 2260002740 S.SW LS8J2M-T T 148.8/15.2
S15 2260002740 S.SW LS8J2M-T T 125.5/3.1
S16 2260002740 S.SW LS8J2M-T T 145.2/3.1
S17 2260002740 S.SW LS8J2M-T T 167.3/3.1
[SW-C BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R1 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 32.7/126.7
R2 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 30.7/122.6
R3 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 30.7/118.1
R4 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 30.6/125.7
R5 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 30.6/100.1
R6 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 30.6/97.4
R7 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 31.9/94.7
R8 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 31.9/101.7
R9 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 34.8/71.3
R10 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 35.5/69.3
R11 7030003580 S.RES ERJ3GEYJ 153 V (15 k) B 35.5/66.6
R12 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 32.7/84.5
R13 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k) B 43.1/46.9
R14 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 49.2/44.4
R15 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k) B 43.1/50.6
R51 7030003400 S.RES ERJ3GEYJ 471 V (470) B 38.3/124.2
R52 7030003400 S.RES ERJ3GEYJ 471 V (470) B 41.2/124.2
R53 7030003400 S.RES ERJ3GEYJ 471 V (470) B 37.9/107.7
R54 7030003400 S.RES ERJ3GEYJ 471 V (470) B 46.6/102.1
R55 7030003400 S.RES ERJ3GEYJ 471 V (470) B 43.2/98.8
R56 7030003400 S.RES ERJ3GEYJ 471 V (470) B 46.6/99.4
R57 7030003400 S.RES ERJ3GEYJ 471 V (470) B 48.7/89.9
R58 7030003400 S.RES ERJ3GEYJ 471 V (470) B 48.7/93.3
C1 4030011600 S.CER C1608 JB 1E 104K-T B 28.9/94.5
C2 4030011600 S.CER C1608 JB 1E 104K-T B 41.2/82
C3 4030011600 S.CER C1608 JB 1E 104K-T B 32.1/71.3
C4 4030011600 S.CER C1608 JB 1E 104K-T B 43.5/82.4
J1 6510021721 S.CNR 30FLT-SM2-TB (LF) (SN) B 37.9/89
J2 6510019971 S.CNR 52808-1071 B 44.2/113.1
DS51 5040002930 S.LED SML-512MW T86 T 36.5/123.3
DS52 5040002930 S.LED SML-512MW T86 T 48/123.3
DS53 5040002930 S.LED SML-512MW T86 T 36.5/104.8
DS54 5040002930 S.LED SML-512MW T86 T 48/104.8
DS55 5040002930 S.LED SML-512MW T86 T 36.5/94.8
DS56 5040002930 S.LED SML-512MW T86 T 48/94.8
DS57 5040002930 S.LED SML-512MW T86 T 36.5/84.8
DS58 5040002930 S.LED SML-512MW T86 T 48/84.8
S1 2260002740 S.SW LS8J2M-T T 36.7/129.1
S2 2260002740 S.SW LS8J2M-T T 48.2/129.1
S3 2260002740 S.SW LS8J2M-T T 36.7/118.9
S4 2260002740 S.SW LS8J2M-T T 48.2/118.9
S5 2260002740 S.SW LS8J2M-T T 36.7/100.4
S6 2260002740 S.SW LS8J2M-T T 48.2/100.4
S7 2260002740 S.SW LS8J2M-T T 36.7/90.4
S8 2260002740 S.SW LS8J2M-T T 48.2/90.4
S9 2260002740 S.SW LS8J2M-T T 36.7/80.4
S10 2260002740 S.SW LS8J2M-T T 48.2/80.4
S11 2260002740 S.SW LS8J2M-T T 36.7/70
S12 2260002740 S.SW LS8J2M-T T 36.7/61.2
S13 2260002740 S.SW LS8J2M-T T 36.7/52.4
S14 2260002740 S.SW LS8J2M-T T 36.5/42.7
S15 2260002740 S.SW LS8J2M-T T 61.5/42.7
S16 2260002740 S.SW LS8J2M-T T 12.2/32.4
S17 2260002740 S.SW LS8J2M-T T 74.3/27.4
S18 2260002740 S.SW LS8J2M-T T 12.2/14.7
S19 2260002740 S.SW LS8J2M-T T 75.2/14.2
S20 2260002740 S.SW LS8J2M-T T 12.2/2.3
S21 2260002740 S.SW LS8J2M-T T 75.2/2.3
S22 2260002740 S.SW LS8J2M-T T 25.7/2.3
