Icom IC-F29SR - ACCESSORIES; Accessory attachments

Section 1
1
ACCESSORIES
Accessory attachments
Battery pack D
Attach or remove the battery pack, as illustrated to the
right.
To attach the battery pack:
Place the tabs on the bottom of the battery pack into q
the slots at the bottom of the transceiver. (q)
Push the battery pack until the battery release but- w
tons make a ‘click’ sound. (w)
To remove the battery pack:
Push the battery release buttons in the direction of q
the arrow as shown to the right. (e)
The battery pack is then released, and you can re- w
move it. (r)
Battery release
buttons
q
w
e
e
r
To attach To remove
To attach
To detach
w
e
Ta b
q
Belt clip D
NOTE: Before attaching or detaching the belt clip,
remove the battery pack from the transceiver, if it is
attached.
To attach the belt clip:
Slide the belt clip in the direction of the arrow until ➥
the belt clip locks in place, and makes a ‘click’ sound.
(q)
To detach the belt clip:
Lift the tab up ( ➥ w), and slide the belt clip in the direc-
tion of the arrow (e).
