SPECIFICATIONS
10
11
■ Specifications
ïï
General
• Frequency coverage :
Transmit 156.025–157.425 MHz
Receive 156.050–163.275 MHz
• Mode : FM (16K0G3E)
DSC(16K0G2B)
• Channel spacing : 25 kHz
• Current drain (at 13.8 V) : TX high 5.5 A max.
Max. audio 1.5 A max.
• Power supply requirement : 13.8 V DC
• Frequency stability : ±10 ppm
(–20°C to +60°C; –4°F to +140°F)
• Dimensions : 153(W) × 67(H) × 132(D) mm
(Projections not included) 6
1
⁄32(W) × 2
5
⁄8(H)× 5
3
⁄16(D) in
• Weight : Approx. 825 g ; 1.8 lb
ïï
Transmitter
• Output power : 25 W and 1 W
• Modulation system : Variable reactance frequency
modulation
• Max. frequency deviation : ±5.0 kHz
• Spurious emissions : Less than –70 dB
ïï
Receiver
• Receive system : Double conversion
superheterodyne
• Sensitivity (12 dB SINAD) : 0.22µV (typical)
• Squelch sensitivity : Less than 0.22µV
• Intermodulation rejection ratio : More than 70 dB
•
Spurious response rejection ratio
: More than 70 dB
• Adjacent channel selectivity : More than 70 dB
• Audio output power : 4.5W (typical) at 10%
distortion with a 4 Ω load
All stated specifications are subject to change without notice or
obligation.
