Icom IC-M33 - Optional Battery Charger

24
8
BATTERY CHARGING
■ Optional battery charger
D BC-162 installation
D Charging
q Connect the AC adapter as shown below.
w Insert the battery pack with/without the transceiver into
the charger.
 •Thechargeindicatorlightsorange.
 •Thechargeindicatorblinksorange(orred)whentheprotector
is activated.
e Charge the battery pack approx. 2 hours, depending on
the remaining battery charge.
 •Thechargeindicatorlightsgreenwhenchargingiscompleted.
NOTE: The battery charger, BC-162, has a charging
timer. The timer stops the charging process after 4
hours (approx.).
Supplied screwsSupplied screws
• To a desktop • To a wall
• For added stability
Eyelet:
Use a rubber band to
secure the transceiver,
if desired.
BC-162
Charge
indicator
Tu rn power OFF
Battery pack
Transceiver
AC adapter
(Not supplied with
some versions)
