Icom IC-M601 - LOGIC BOARD PARTS LIST (CONTINUED); AF UNIT PARTS LIST (CONTINUED)

S.=Surface mount
[AF UNIT][LOGIC BOARD]
DS20 5040002660 S.LED FY1101F-TR (LED)
DS21 5040002660 S.LED FY1101F-TR (LED)
DS22 5040002660 S.LED FY1101F-TR (LED)
DS23 5040002660 S.LED FY1101F-TR (LED)
DS24 5040002660 S.LED FY1101F-TR (LED)
DS25 5040002660 S.LED FY1101F-TR (LED)
S1 2230000250 SWITCH SPPH22014A
BT1 3020000110 LITHIUM CR2032
EP1 0910055503 PCB B 5882C
IC1 1110002030 IC TA7808S
IC2 1180000420 S.IC TA78L05F (TE12R)
IC3 1110003090 IC LA4425A
IC4 1130007690 S.IC BU4066BCF-E2
IC5 1130007690 S.IC BU4066BCF-E2
IC6 1110003750 S.IC M5218AFP 600C
IC7 1130007690 S.IC BU4066BCF-E2
IC8 1110003750 S.IC M5218AFP 600C
IC9 1110003750 S.IC M5218AFP 600C
IC10 1110005800 IC TA8225L
IC11 1110004520 S.IC M5222FP 600C
IC12 1170000350 S.IC PC357N6T
IC13 1130011120 S.IC BU4584BFV-E2
IC14 1110002400 S.IC NJM2107F-TE1
IC16 1130007690 S.IC BU4066BCF-E2
IC17 1130007570 S.IC BU4094BCFV-E2
IC18 1130007570 S.IC BU4094BCFV-E2
IC19 1130007430 S.IC TC7S14FU (TE85R)
IC20 1110002400 S.IC NJM2107F-TE1
Q1 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q2 1590000430 S.TRANSISTOR DTC144EUA T106
Q7 1530002550 S.TRANSISTOR 2SC3326-B (TE85R)
Q8 1590000430 S.TRANSISTOR DTC144EUA T106
Q9 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q11 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q12 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q13 1590001390 S.FET 2SJ144-Y (TE85R)
Q18 1560000810 S.FET 2SK1069-4-TL
Q21 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q22 1530002280 S.TRANSISTOR 2SC4081 T106 S
Q23 1590000430 S.TRANSISTOR DTC144EUA T106
Q24 1560000810 S.FET 2SK1069-4-TL
Q25 1530002280 S.TRANSISTOR 2SC4081 T106 S
Q26 1510000510 S.TRANSISTOR 2SA1576A T106R
Q28 1560000810 S.FET 2SK1069-4-TL
Q29 1530002280 S.TRANSISTOR 2SC4081 T106 S
Q30 1510000510 S.TRANSISTOR 2SA1576A T106R
Q51 1520000380 TRANSISTOR 2SB1143 S
Q52 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q53 1540000550 S.TRANSISTOR 2SD1664 T100Q
D1 1790000700 DIODE DSA3A1
D2 1750000550 S.DIODE 1SS355 TE-17
D5 1160000080 S.DIODE DAP202K T146
D6 1750000150 S.DIODE DA204K T146
D7 1750000550 S.DIODE 1SS355 TE-17
D8 1730002360 S.ZENER MA8062-M (TX)
D11 1750000550 S.DIODE 1SS355 TE-17
D12 1750000550 S.DIODE 1SS355 TE-17
D13 1750000150 S.DIODE DA204K T146
D14 1730002360 S.ZENER MA8062-M (TX)
D15 1730002360 S.ZENER MA8062-M (TX)
R1 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R11 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R12 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R13 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R14 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R15 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R16 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R17 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R18 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R19 7030000100 S.RESISTOR MCR10EZHJ 4.7 Ω (4R7)
R20 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R21 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R31 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R32 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R33 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R34 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 kΩ)
R35 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R36 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R37 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R38 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R39 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R40 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R41 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R42 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R43 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R44 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R45 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R46 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R47 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R48 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R49 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R50 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R51 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R52 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R53 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R54 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R55 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R56 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R57 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R59 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R60 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R61 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R62 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R63 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R64 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R67 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R68 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R69 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R71 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R72 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R73 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R74 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ)
R75 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R76 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R79 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R80 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R81 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R82 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R83 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R84 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R85 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R86 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R87 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R88 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R89 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R90 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R91 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R92 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R94 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R95 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R96 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R97 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R197 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R198 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R199 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R201 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R202 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R203 7030003790 S.RESISTOR ERJ3GEYJ 824 V (820 kΩ)
R204 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R205 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R206 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R207 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R208 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
6 - 3
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[AF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
