Icom IC-M601 - AF UNIT PARTS LIST (CONTINUED); MAIN UNIT PARTS LIST

S.=Surface mount
[MAIN UNIT][AF UNIT]
C261 4030012600 S.CERAMIC C2012 JB 1A 105M-T
C262 4030012600 S.CERAMIC C2012 JB 1A 105M-T
C263 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C265 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C266 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C267 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C271 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C272 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C273 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C274 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C275 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C276 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C277 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C278 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C279 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C280 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C281 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C282 4030011810 S.CERAMIC C1608 JB 1A 224K-T
C283 4030011810 S.CERAMIC C1608 JB 1A 224K-T
C301 4510004630
S.ELECTROLYTIC ECEV1CA100SR
RL1 6330001670 RELAY FTR-P3CP012W1
RL2 6330001620 RELAY FTR-F3AA012E
RL3 6330001460 RELAY FTR-F1CA012V
J1 6510023510 S.CONNECTOR 28FLT-SM1-TB
J2 6510022620 S.CONNECTOR 10FMN-BMTTR-A-TBT
J3 6510016430 S.CONNECTOR 53307-1491
J4 6510023090 S.CONNECTOR 20FLT-SM1-TB
J5 6510023420 CONNECTOR SB4P-HVQ-A
J6 6510019370 S.CONNECTOR B3B-ZR-SM3-TF
J7 6510018960 S.CONNECTOR B2B-PH-SM3-TB
J8 6510003380 CONNECTOR B02B-EH-S
J9 6510020800 CONNECTOR OP-10
J10 6510020800 CONNECTOR OP-10
W4 7030003860 S.JUMPER ERJ3GE JPW V
W5 7030003860 S.JUMPER ERJ3GE JPW V
W6 8900011870 CABLE OPC-1203
EP1 0910056054 PCB B 5880D
EP2 6910013370 S.BEAD
BLM18BB221SN1D (BLM11B221SB)
EP3 6910013370 S.BEAD BLM18BB221SN1D (BLM11B221SB)
IC1 1110003490 S.IC TA31136FN (D,EL)
IC2 1120002830 S.IC NJM2125F-TE1
IC3 1110003780 S.IC NJM2902V-TE1
IC4 1110003650 S.IC NJM2211M-TE1 [HOL], [FRG] only
IC5 1130011120 S.IC BU4584BFV-E2
IC6 1110003490 S.IC TA31136FN (D,EL)
IC9 1110003650 S.IC NJM2211M-TE1
IC11 1130005640 S.IC TC4W53F (TE12L)
IC12 1130007610 S.IC µPD3140GS-E1 (DS8)
IC13 1150002080 IC RA35H1516M-01
IC14 1110002400 S.IC NJM2107F-TE1
IC15 1190000350 S.IC M62363FP-650C
Q1 1580000750 S.FET 3SK294 (TE85L)
Q2 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q3 1560000990 S.FET PMBFJ310
Q4 1560000990 S.FET PMBFJ310
Q7 1580000750 S.FET 3SK294 (TE85L)
Q8 1560000990 S.FET PMBFJ310
Q9 1560000990 S.FET PMBFJ310
Q10 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q11 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q12 1560000990 S.FET PMBFJ310
Q13 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q14 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q15 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q16 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q17 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q18 1560000990 S.FET PMBFJ310
Q19 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q21 1590000720 S.TRANSISTOR DTA144EUA T106
Q22 1590000430 S.TRANSISTOR DTC144EUA T106
Q23 1530003420 S.TRANSISTOR 2SC5110-O (TE85R)
Q27 1530003420 S.TRANSISTOR 2SC5110-O (TE85R)
Q28 1530002240 S.TRANSISTOR 2SC3775-3-TB
Q29 1590000430 S.TRANSISTOR DTC144EUA T106
Q30 1530002240 S.TRANSISTOR 2SC3775-3-TB
Q32 1590000660 S.TRANSISTOR DTC144TU T106
Q33 1590000430 S.TRANSISTOR DTC144EUA T106
Q35 1510000920 S.TRANSISTOR 2SA1577 T106 Q
Q36 1590000430 S.TRANSISTOR DTC144EUA T106
D1 1710001080 DIODE XB15A308
D11 1750000430 S.DIODE HSB88WSTR
D12 1790001330 S.ZENER MA8036-L (TX)
D15 1790000980 S.DIODE MA742 (TX)
D21 1750000430 S.DIODE HSB88WSTR
D22 1790001330 S.ZENER MA8036-L (TX)
D32 1720000810 S.VARICAP HVC358BTRF
D33 1720000810 S.VARICAP HVC358BTRF
D35 1720000660 S.VARICAP 1SV288 (TPH2)
D37 1720000260 S.VARICAP 1SV214 (TPH2)
D39 1720000260 S.VARICAP 1SV214 (TPH2)
D40 1720000260 S.VARICAP 1SV214 (TPH2)
D41 1790001620 S.DIODE 1SV308 (TPL3)
D42 1790000620 S.DIODE MA77 (TX)
D43 1790000620 S.DIODE MA77 (TX)
D44 1750000550 S.DIODE 1SS355 TE-17
D46 1710001080 DIODE XB15A308
D47 1790000690 S.DIODE HSM88ASR-TR
D48 1790000690 S.DIODE HSM88ASR-TR
D49 1730002320 S.ZENER MA8051-M (TX)
D52 1790001250 S.DIODE MA2S111-(TX)
FI1 2030000250 MONOLITH FL-285 IMD:-100 (31.05 MHz)
FI3 2020001840 CERAMIC ALFYM450F=K
FI4 2030000240 MONOLITH FL-298 IMD:-100 (21.7 MHz)
FI5 2010002330 MONOLITH FL-298 (21.700 MHz)
FI6 2020001840 CERAMIC ALFYM450F=K
X1 6070000190
S.DISCRIMINATOR CDBCB450KCAY24-R0
X2 6070000190 S.DISCRIMINATOR CDBCB450KCAY24-R0
X3 6050011590 S.XTAL CR-744 (21.25 MHz)
X4 6050011070 S.XTAL CR-664A (15.300 MHz)
L1 6110001600 COIL LA-243
L2 6110001600 COIL LA-243
L3 6110001600 COIL LA-243
L4 6110001580 COIL LA-238
L11 6190001590 COIL E526HNA-100312
L12 6190001590 COIL E526HNA-100312
L13 6190001590 COIL E526HNA-100312
L14 6190001590 COIL E526HNA-100312
L15 6190001590 COIL E526HNA-100312
L18 6130002960 S.COIL 617DB-1327=P3
L19 6130002960 S.COIL 617DB-1327=P3
L20 6200001830 S.COIL NL 322522T-100J
L21 6200002430 S.COIL NL 252018T-082J
L22 6200008090 S.COIL LQW2BHN68NJ01L
L25 6200002860 S.COIL NL 252018T-4R7J
L26 6200010520 S.COIL C2520C-R75G (0.75U)
L31 6190001580 COIL E544ENAS-100014
L32 6190001580 COIL E544ENAS-100014
L33 6190001580 COIL E544ENAS-100014
L34 6190001580 COIL E544ENAS-100014
L48 6130002960 S.COIL 617DB-1327=P3
L49 6130002960 S.COIL 617DB-1327=P3
L50 6200001830 S.COIL NL 322522T-100J
L51 6200002160 S.COIL ELJNC 82NK-F
L52 6200008090 S.COIL LQW2BHN68NJ01L
L55 6200002860 S.COIL NL 252018T-4R7J
L56 6200010440 S.COIL C2520C-1R2G (1.2U)
6 - 5
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
