Icom IC-M601 - MAIN UNIT PARTS LIST (CONTINUED)

S.=Surface mount
[MAIN UNIT]
C370 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C371 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C372 4550006130 S.TANTALUM ECST1VY224R
C373 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C374 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C375 4030007050 S.CERAMIC C1608 CH 1H 220J-T
C376 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C377 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C378 4550006700 S.TANTALUM ECST1AY106R
C379 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C381 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C383 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C385 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C386 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C391 4550006650 S.TANTALUM ECST1CY685R
C392 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C393 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C397 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C398 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C399 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C400 4030009520 S.CERAMIC C1608 CH 1H 020B-T
C401 4030007170 S.CERAMIC C1608 CH 1H 221J-T
C402 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C403 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C404 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C405 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C406 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C407 4030009920 S.CERAMIC C1608 CH 1H 050B-T
C408 4030011770 S.CERAMIC C1608 CH 1H 060B-T
C409 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C410 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T
C411 4030009510 S.CERAMIC C1608 CH 1H 010B-T
C412 4030006990 S.CERAMIC C1608 CH 1H 080D-T
C413 4030009350 S.CERAMIC C1608 CH 1H 3R5B-T
C414 4030009560 S.CERAMIC C1608 CH 1H R75B-T
C415 4030009560 S.CERAMIC C1608 CH 1H R75B-T
C416 4030006990 S.CERAMIC C1608 CH 1H 080D-T
C417 4030009350 S.CERAMIC C1608 CH 1H 3R5B-T
C418 4030009510 S.CERAMIC C1608 CH 1H 010B-T
C419 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T
C420 4030007020 S.CERAMIC C1608 CH 1H 120J-T
C421 4030009530 S.CERAMIC C1608 CH 1H 030B-T
C423 4030007100 S.CERAMIC C1608 CH 1H 560J-T
C427 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C428 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C431 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C432 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C433 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C434 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C435 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C436 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C437 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C438 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C439 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C440 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C441 4030006860 S.CERAMIC C1608 JB 1H 102K-T
J1 6510023360 S.CONNECTOR 26FLT-SM1-TB
J2 6510022620 S.CONNECTOR 10FMN-BMTTR-A-TBT
J3 6510007020 CONNECTOR TMP-J01X-V6
W1 7030003860 S.JUMPER ERJ3GE JPW V
W2 7030003860 S.JUMPER ERJ3GE JPW V
W3 7030003860 S.JUMPER ERJ3GE JPW V
W4 7030003860 S.JUMPER ERJ3GE JPW V
W5 7030003860 S.JUMPER ERJ3GE JPW V
W6 7030003860 S.JUMPER ERJ3GE JPW V
W7 7030010840 S.JUMPER MJP-0.2-T
W8 7030010850 S.JUMPER MCR100JZHJ JPW
W9 7030010850 S.JUMPER MCR100JZHJ JPW
W10 7030010850 S.JUMPER MCR100JZHJ JPW
W11 7030010850 S.JUMPER MCR100JZHJ JPW
W12 7030010860 JUMPER MJP-0.6
EP1 0910056045 PCB B 5879E
EP2 6910013370 S.BEAD BLM18BB221SN1D
EP3 6910002160 CASE BM7
6 - 10
REF ORDER
DESCRIPTION
NO. NO.
6-2 HM-137
[MAIN UNIT]
R1 7010006890 RESISTOR R20J 12 kΩ
R2 7010006880 RESISTOR R20J 6.8 kΩ
R3 7010006900 RESISTOR R20J 15 kΩ
R4 7010006910 RESISTOR R20J 33 kΩ
R5 7070001150 RESISTOR MOS2W-150-J <KN>
C1 4010007711 CERAMIC HE40SJ YB 471K 50V
C2 4030017280 S.CERAMIC C1608 CH 1H 471J-T-A <KN>
J1 6510022450 CONNECTOR S07B-EH-S <KN>
MC1 7700002120 MICROPHONE KUC2123-030245
S1 2260002330 SWITCH SKHHLP014A
S2 2260002340 SWITCH SKHHAM024A
S3 2260002340 SWITCH SKHHAM024A
S4 2260002340 SWITCH SKHHAM024A
SP1 2510001092 SPEAKER S36D0801B <KN>
W1 9044902012 WIRE 71/98/010/X98/X98
W2 9044902012 WIRE 71/98/010/X98/X98
W3 9045995030 WIRE 71/98/020/X98/X98
W4 9045995030 WIRE 71/98/020/X98/X98
EP1 0910052553 PCB B 5431C
EP2 9029701901 TUBE IRRAX 0.7 (d) L=4 mm
REF ORDER
DESCRIPTION
NO. NO.
