Icom IC-M601 - MAIN UNIT PARTS LIST (CONTINUED)

S.=Surface mount
[MAIN UNIT]
C72 4550005980 S.TANTALUM TEMSVA 1A 475M-8L
C73 4510005370 S.ELECTROLYTIC ECEV1AA221P
C74 4510004540 S.ELECTROLYTIC ECEV0JA470SR
C75 4030008980 S.CERAMIC C2012 JB 1C 154K-T-A
C76 4030008980 S.CERAMIC C2012 JB 1C 154K-T-A
C77 4030006900 S.CERAMIC C1608 JB 1H 103K-T-A
RL1 6310000040 S.RELAY FTR-B3GA4.5Z-SP-B10
J1 6510019420 S.CONNECTOR B8B-ZR-SM3-TF
DS1 5030001900 LCD A0119 (LCD 36
×28.5)
DS2 5040002660 S.LED FY1101F-TR (LED)
DS3 5040002660 S.LED FY1101F-TR (LED)
DS4 5040002310 S.LED SML-311YTT86
DS5 5040002660 S.LED FY1101F-TR (LED)
DS6 5040002660 S.LED FY1101F-TR (LED)
DS7 5040002310 S.LED SML-311YTT86
DS8 5040002310 S.LED SML-311YTT86
DS9 5040002310 S.LED SML-311YTT86
DS10 5040002310 S.LED SML-311YTT86
MC1 7700002480 MICROPHONE SKB-2746 LPC
S1 2260002710 S.SWITCH SKQLLCE012
S2 2260002710 S.SWITCH SKQLLCE012
S3 2260002710 S.SWITCH SKQLLCE012
S4 2260002710 S.SWITCH SKQLLCE012
W15 7030003860 S.JUMPER ERJ3GE JPW V
W16 7030003860 S.JUMPER ERJ3GE JPW V
W17 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910055022 PCB B 5778B
EP2 8930051120 LCD CONTACT SRCN-2320-SP-N-W
6 - 12
REF ORDER
DESCRIPTION
NO. NO.
