Icom IC-M602 Instruction Manual

10
TROUBLESHOOTING
60
PROBLEM POSSIBLE CAUSE SOLUTION REF.
No power comes ON.
•Bad connection to the power supply. •Check the connection to the transceiver. p. 55
No sound comes from
the speaker.
•Squelch level is too high.
•Volume level is too low.
•Speaker has been exposed to water.
•Internal speaker is turned OFF.
•Set squelch to the threshold point.
•Set [VOL] to a suitable level.
•Drain water from the speaker.
• Turn the internal speaker ON in set mode.
p. 10
p. 10
—
p. 52
Transmitting is impossi-
ble, or high power can-
not be selected.
•Some channels are for low power or re-
ceive only.
•The output power is set to low.
•Change channels.
•Push [H/L] to select high power.
pgs.
8, 61
p. 10
Scan does not start. •“TAG ” channel is not programmed. •Set the desired channels as “TAG” chan-
nels.
p. 17
No beep sounds. •Beep tone is turned OFF.
• The squelch is open.
• Turn the beep tone ON in set mode.
•Set squelch to the threshold point.
p. 52
p. 10
Receive signal cannot
be understood.
•Optional voice scrambler is turned OFF.
•Scramble code is not set correctly.
•Turn the optional voice scrambler ON.
•Reset the scramble code.
p. 13
p. 53
Sensitivity is low. •The attenuator is activated. • Push [F], then [6 LO/DX] to turn the function OFF. p. 10
Distress call cannot be
transmitted.
•MMSI (DSC self ID) code is not pro-
grammed.
•Program the MMSI (DSC self ID) code. p. 18

Icom IC-M602 Specifications

General

Type	Marine VHF Transceiver
Frequency Range	156.000 - 163.425 MHz
Antenna Impedance	50Ω
Weight	1.5 kg
Waterproof Rating	IPX7
Modulation System	FM
Sensitivity	0.25 μV (12 dB SINAD)
Intermodulation Rejection Ratio	70 dB
Spurious Response Rejection Ratio	70 dB
Audio Output Impedance	4Ω
Output Power	25W / 1W
Power Supply	13.8 V DC
Operating Temperature Range	-15°C to +55°C
Adjacent Channel Power	70 dB
FM Hum and Noise	40 dB
Squelch Sensitivity	0.25 μV
Usable Channels	USA, Canada, International
Type of Emission	16K0G3E (FM), 16K0G2B (DSC)
Current Drain	5.5 A (at 25 W), 1.5 A (at 1 W)
Spurious Emissions	-70 dBc (High), -60 dBc (Low)
