ACCESSORIES
2
■ Supplied accessories
Antenna Handstrap Belt clip
Battery pack
Power adapter
(For Desktop charger)
Desktop charger
(With 2 screws)
Cigarette lighter cable
NOTE: Some accessories may not be supplied, or the shape may be di󰀨erent,
depending on the transceiver version.
■ Attaching accessories
D Antenna
Connect the supplied antenna to the antenna connector.
CAUTION:
• DO NOT carry the transceiver by holding only the
antenna.
• DO NOT connect an antenna other than those listed in
this instruction manual.
• DO NOT transmit without an antenna.
D Belt clip
To attach:
Slide the belt clip in the direction of the
arrow until the belt clip is locked and
makes a ‘click’ sound.
To detach:
Lift the tab up (1), and slide the belt clip in
the direction of the arrow (2).
BE CAREFUL! DO NOT break your
ngernail.
q
w
Belt clip
q
w
