2
Click to display the IC-R8600
I/Q Settings screen. (p. 3)
Click to start or
stop receiving.
Click to quit the software.
L The receiver automatically returns to the normal
(Local) mode after closing the software.
Click to display the Sound
Card selection screen.
Click to set the LO frequency.
Click to set the Tune frequency.
Main Screen
Waterfall Display (RF)
Spectrum Display (RF)
Waterfall Display (AF)
Spectrum Display (AF)
Tune frequency Marker
Click to select the receiving mode.
Adjust the audio level.
(This is only an example.)
Click to select the sampling
rate value.
L The needed output
sampling rate depends on
the receiving mode.
To Next Page
