S.=Surface mount
6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R61 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 107.6/7.3
R64 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 103.6/6.1
R66 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 101.1/4.1
R68 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 92.2/15.9
R69 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 92.7/18.2
R70 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) B 98/13
R71 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 96.2/19.8
R72 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) B 101.5/14.4
R75 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 101.4/17
R77 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 93.2/20.1
R79 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) B 95/30.2
R80 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 95.9/32
R81 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 102.5/30.9
R82 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) T 97.9/30.2
R83 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 98.4/31.8
R84 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 105/32.8
R85 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 102.9/38
R86 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 98.2/38.4
R87 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 97.2/40.4
R88 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 96.2/38.4
R93 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 104.6/18
R94 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 107.9/12.4
R95 7030007310 S.RES ERJ2GEJ 155 X (1.5 M
Ω
) B 108.5/15
R97 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 89.1/15.8
R98 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 80.2/17.5
R99 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) B 105.1/16
R100 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 105/10.9
R101 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 34.7/12.6
R102 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 35.9/13.1
R103 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 31.5/13.7
R104 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 104.9/15
R105 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 98.2/16.8
R107 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 80.7/16
R108 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 99.2/15.2
R112 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 88.5/13.8
R113 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 80.7/14.9
R114 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) T 97.6/13.7
R115 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 96.7/12.7
R117 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 96.7/11.7
R120 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 62.6/20.4
R121 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) B 65.9/20.4
R122 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) B 65.3/16.2
R123 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) B 66.9/20.4
R126 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) B 63.5/8.1
R127 7030007260 S.RES ERJ2GEJ 330 X (33
Ω
) B 67.4/14.6
R128 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 73.8/4.4
R130 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 29.6/10.6
R131 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) B 26.5/10.5
R132 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 93.7/2
R136 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 23.5/40.9
R137 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 20.6/16.9
R139 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 110.5/35
R141 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 107.2/32.1
R144 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 82.4/3.1
R148 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 29.9/14.1
R150 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 69.5/27.9
R155 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 67.7/1.9
R159 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 105/11.9
R160 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 109.2/9.5
R161 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 111.8/14
R162 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 111.8/15
R163 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 111.8/13
R164 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 26.9/28.9
R169 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) T 76.3/18.2
R170 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 79.4/13.5
R174 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 93.4/2.8
R176 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 103.3/17.5
R177 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 100.2/16.5
R178 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 107.1/15.5
R181 7030010080 S.RES ERJ2RHD 104 X (100 k
Ω
) B 45.4/8.2
R182 7510001660 S.TMR NTCG16 4LH 473KT B 49.8/8.8
R184 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 75.3/29.9
R185 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 76/25.9
R186 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 74.7/22.4
R187 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 104.8/7.7
R193 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 50.2/12
R194 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 48.6/12.4
R195 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 48.8/13.4
R196 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 49.3/10.9
R204 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 65.2/3.5
R205 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 66.4/1.9
R210 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) T 108.7/14.3
R222 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 106.4/2.6
R224 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) B 47.7/9.2
R225 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 25.8/17.2
R227 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 47.8/10.4
R228 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 25.8/16.2
R240 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 29.9/15.8
R244 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 102.5/31.9
R245 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 32.5/17.7
R246 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 36.1/14.3
R251 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 105.5/18.6
R252 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) B 109/2.2
R257 7030010040 S.RES ERJ2GE-JPW T 88.1/16.8
R258 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 107.8/3.2
R259 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 103.6/2.9
R260 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 109.7/34
R261 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 115.5/35.2
R262 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 98.6/20.3
R266 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 23.9/17.4
R318 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 51.4/37.2
R319 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 47.4/36.1
R320 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 47.4/37.1
R321 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 50.2/38.3
R323 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 45.4/37.9
R324 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) B 45.7/39.6
R325 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 49.3/40.6
R326 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 51.4/39.1
R327 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 45.1/36.6
R328 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 101/28.4
R329 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 100.5/30
R330 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 117.6/37.5
R331 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 119.4/38.8
R332 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
Ω
) B 119.2/35
R333 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 122.8/30.4
R334 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 120.8/34.2
R335 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 117.9/35.7
R336 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 49.2/38.3
R337 7030007310 S.RES ERJ2GEJ 155 X (1.5 M
Ω
) T 88/18.6
R340 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 113.9/18.5
R341 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 115.4/18.6
R346 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 30.9/15.8
R357 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 112.1/18.5
R358 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 110.6/20
R362 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 29.8/32.3
R363 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 11.4/41.9
R364 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 10.1/40.1
R367 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 15.5/30.7
R368 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 15/32
R369 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 31.8/40.6
R370 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 33.1/40.1
R371 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 10.1/24.8
R372 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 9.1/26.5
R373 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 13.2/23
R374 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 12.2/23
R375 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 10.1/28.3
R376 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 17.2/30
R377 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) B 38.7/38.8
R378 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 38.7/40.4
R379 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 38.7/41.9
R380 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 40.3/41.9
R381 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 27.1/42.3
R382 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 26.9/27.9
R384 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 22.6/5.9
R385 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 20.9/5.2
R386 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 17.4/32.7
R387 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 98.2/28.9
R388 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 92.3/24.9
R389 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 99.4/22.8
R397 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
Ω
) T 96.9/16
R398 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 35.8/8.6
R402 7030010040 S.RES ERJ2GE-JPW T 89.9/29.1
R405 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 60.2/7.7
R406 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 57.2/5.7
R413 7030010040 S.RES ERJ2GE-JPW T 106/16.6
R417 7030010040 S.RES ERJ2GE-JPW B 90.9/18.5
R418 7030010040 S.RES ERJ2GE-JPW B 90.1/15.2
R419 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 89.7/16.4
R420 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 90.1/18.7
R421 7030010040 S.RES ERJ2GE-JPW T 89.6/19.9
R422 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 85.8/20.2
R423 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 85.2/22.2
R424 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 86.3/24.8
R425 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 84.6/25.2
R426 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 79.4/20.6
R427 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 81.6/20.1
R428 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 81.6/22.7
R429 7030005710 S.RES ERJ2GEJ 121 X (120
Ω
) B 81.1/21.4
R430 7030007250 S.RES ERJ2GEJ 220 X (22
Ω
) B 86.3/25.8
R431 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 87.3/27.6
R432 7030007320 S.RES ERJ2GEJ 225 X (2.2 M
Ω
) T 90.9/37.9
R433 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 77.9/19.6
R434 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 75.9/20.9
R435 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) B 80.6/23.3
R436 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) B 77.5/24.2
R437 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 79.5/28.9
R438 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 80.5/29.2
R439 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 81.5/29.2
R440 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 76.9/29.5
R441 7030007320 S.RES ERJ2GEJ 225 X (2.2 M
Ω
) T 80/30.2
R442 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 78.8/30.7
R443 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 75.6/32.7
R444 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 75.6/33.7
R445 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) T 78.8/32.4
R446 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) T 75.6/31.2
R447 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) T 81.7/25.8
R448 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) T 83/26.7
R449 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 83/28.4
R455 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 95.5/33.3
R456 7030010040 S.RES ERJ2GE-JPW B 95.5/34.3
[EU1/2/3]=EUR-1/2/3, [EX1/2/3/4]=EXP-1/2/3/4, [US1/2/3]=USA-1/2/3, [CS1/2/3]=CSA-1/2/3
To Next Page
Loading...
