7 PHYSICAL CHARACTERISTIC
7.1 PHYSICAL DESCRIPTION
7.1.1 Display
* Display:
* I-SAFE 1: Matrix 24 lines 32 columns with red and green LED + white LEDS flash lamp
* I-SAFE 2:
* Red and green LEDs 7-segments digits + white LEDs flash
* Lower display: matrix 16 lines 52 columns amber LEDs
* Doppler radar
* ABS plastic case with mounting hooks
* Built-in solar regulator
* Front face antireflective lexan, UV treated
* 2 boxes on the back for USB plug and parameters encoder
* 1 battery slot on the side
7.1.2 Available accessories
* Battery
* Solar power
* External charger (110 V - 220 V or public lighting)
* Bluetooth communication
* GPRS communication
7.1.3 Dimensions
* Width: 665 mm
* Height: 775 mm
* Thickness: 140 mm,
* Mounting hooks spacing: 475 mm
* Total weight without battery:
* I-SAFE 1: 12.4 kg
* I-SAFE 2: 11.4 kg
* Display window dimensions: 384x513 mm
7.2 TECHNICAL FEATURES
7.2.1 Accuracy of measurements
The accuracy of measures in laboratory is more than 98 %-. This accuracy is only reached for the best
distance of measurement (60 to 80 m for cars and more for trucks).
7.2.2 Range of speed to be detected
The range of speed to be detected runs from 5 to +/- 250 km/h. It is possible to define a speed area
for the display, by fixing minimum and maximum thresholds (see p. 22). Measurements above 5 km/h
are memorised, whatever the choice of display.
