7-8 DESCRIPTION OF AIRPLANE AND SYSTEMS / INSTRUMENT PANELS
ICON A5-B / PILOT’S OPERATING HANDBOOK CHANGE A2
CHAPTER 7
Fuse Panel with Garmin G3X Touch™ with Autopilot
Fuel Shutoff Valve
The fuel shutoff valve (4) is the main shutoff for the fuel
system. It has a detent into the ‘ON’ position and the locking
knob must be pulled and handle rotated simultaneously in
order to turn off the fuel.
ELT Remote Control and Audio Alert Indicator
