ICON A5-B - Aircraft Dimensional Data

6-2 WEIGHT, BALANCE, AND EQUIPMENT LIST / AIRCRAFT DIMENSIONAL DATA
ICON A5-B / PILOT’S OPERATING HANDBOOK CHANGE A3
CHAPTER 6
6.2 AIRCRAFT DIMENSIONAL DATA
6.2.1 AIRCRAFT REFERENCE DATUMS
FIGURE 6-1
AIRCRAFT REFERENCE DATUMS
340 280
80
(FS)
Fuselage
Station
300 180 160 140 120 100 320
60
200 220 240 260
FS
294.63
Aft
Jackpoint
FS
153.0
Fuel
FS
84.5
Nose Gear Axle
(1g empty)
FS
147.7
Wing
Jackpoint
FS
154.75
Spar Datum
FS
128.5
Occupants
FS
176.0
Main Gear
Axle
FS
157.0
Baggage
