6-4 WEIGHT, BALANCE, AND EQUIPMENT LIST / OPERATING WEIGHTS AND LOADING
ICON A5-B / PILOT’S OPERATING HANDBOOK CHANGE A3
CHAPTER 6
6.4 OPERATING WEIGHTS AND LOADING
Maximum Human Weight
250 lb
f
per person
Maximum Baggage/Cargo Weight
60 lb
f
WARNING
: Loading a concentrated weight fully aft in the
baggage area may cause an unsafe aft CG
condition.
Minimum Number of Anchor Loops
At least three (3) out of the six (6) provided anchor loops must
be used in order to safely restrain the full baggage/cargo load.
Minimum Load Rating of Cargo Restraints (Pilot Supplied)
1000 lb
f
Full Usable Fuel Weight
120 lb
f
(20 US gal at 6 lb
f
per US gal)
Removable Side Window Weight and Fuselage Station
7.18 lb
f
(total both windows)
FS 127.6
Removable Wind Deflector Weight and Fuselage Station
0.3 lb
f
(total both deflectors)
FS 113.4
6.5 EMPTY WEIGHT AND CG MEASUREMENT WHILE ON GEAR
The airplane empty weight includes engine oil and coolant, unusable
fuel, hydraulic brake fluid, and installed equipment for the aircraft.
The airplane must be weighed and leveled in a level area. The
weighing area should also be calm or indoors to prevent wind from
affecting the readings.
Check the calibration of the scales used to ensure accurate results.
