PERFORMANCE / RATE OF CLIMB 5-7
CHANGE A1 ICON A5-B / PILOT’S OPERATING HANDBOOK
CHAPTER 5
5.9 RATE OF CLIMB
Conditions
1510 lb
f
Flaps—0°
Full throttle
V
Y
—58 KIAS
4000
0 640 1410
20 700 1540
40 760 1660
60 820 1800
80 880 1950
100 950 2100
6000
-20 760 1670
0 830 1830
20 910 2010
40 1000 2190
60 1090 2390
80 1180 2610
8000
-20 1010 2230
0 1120 2480
20 1250 2750
40 1380 3040
60 1520 3360
80 1680 3710
Press Alt
(ft)
Rate of Climb (ft/min)
0°F 20°F 40°F 60°F 80°F 100°F
Sea Level 682 663 646 629 614 598
1000 644 626 609 592 577 562
2000 607 589 571 555 540 525
3000 569 551 534 518 503 488
4000 532 514 497 481 466 451
5000 494 477 460 444 429 415
6000 457 439 423 407 392 377
8000 381 363 346 330 314 300
Press Alt (ft) Temp (°F) Ground Roll (ft)
Total to Clear 50 ft
Obstacle (ft)
