5-2 PERFORMANCE / AIRSPEED CALIBRATION
ICON A5-B / PILOT’S OPERATING HANDBOOK CHANGE A1
CHAPTER 5
5.2 AIRSPEED CALIBRATION
Conditions
Level flight
Assumed zero instrument error
Stall Speed, V
S0
(Flaps and landing gear
down)
39 KIAS
Total Fuel Capacity 20.1 US gallons
Total Usable Fuel 20 US gallons
Approved Types of Fuel
Unleaded automotive fuel with up to 10%
maximum ethanol content meeting ASTM
D4814 with minimum RON 95 (minimum
Anti-Knock Index 91)
Grade 100LL aviation gasoline (AVGAS)
meeting ASTM D910
Max Engine Power at SL 100 hp at 5800 RPM (5 min max)
Max Demonstrated Direct Crosswind
Component—Land and Water (not a
limitation)
12 knots
Service Ceiling at Gross Weight (100
ft/min Climb Rate)
15,000 ft
Flap Setting Airspeeds
Flaps 0°
KIAS 50 60 70 80 90 100 110 120
KCAS 51 61 71 80 90 100 109 119
Flaps 15°
KIAS 45 50 55 60 65 70 75 —
KCAS 46 51 55 60 65 70 74 —
Flaps 30°
KIAS 45 50 55 60 65 70 75 —
KCAS 45 50 54 59 64 68 73 —
Parameter Value
