ICS 695XL Service Manual

©2017 ICS - Blount Inc, Specications subject to change without notice. REV19JUNE2017 P/N 598901
25
695XL SERVICE MANUAL
8.6
Clutch removal.
• Remove clutch cup & rim sprocket rst.
8.7
Insert piston stop tool into spark plug
hole.
8.8
Remove clutch with clutch tool
(P/N 546659).
• Rotate clockwise to remove clutch
(clutch is left-handed thread).
8. CLUTCH & RIM SPROCKET
