©2017 ICS - Blount Inc, Specications subject to change without notice. REV19JUNE2017 P/N 598901
67
695XL SERVICE MANUAL
20.13
Remove the shaft seals from both sides
of the crankcase.
See seal removal.
20.15
Attach universal puller and press out the
crank shaft.
20.14
Install grip plate on the clutch side of the
crankcase.
20. CRANKCASE
