TUNNEL MASTER JR MANUAL

System Hardware 19

J6 485

3 position jumper should be on 2 pins to select 485 Communication

(Left)

J7 OFF

Receive terminating resister.

J8 ON

Network Interface Chassis Ground Jumper

J9 ON

Network Interface Signal Ground Jumper

J10 ON

BIAS Low (-) set ON for the Main Relay box only.

J11 ON

ON = Enables, OFF = Disables manual override switches on relay

box,
