TUNNEL MASTER JR MANUAL
System Hardware 4
Chapter 1
System Hardware and Installation
Overview
Introduction
This chapter provides a brief description of the hardware components
and their function. The Tunnel Master Jr. hardware is designed to
withstand the harsh environments and hard use of a busy car wash.
Both the Relay Box and the Input Station Keypad come with a 3-year,
conditional warranty, against defects in material, workmanship and
operating failure from normal use.
In this chapter
This chapter covers the following topics:
Topic See Page
The Relay Box 5
The Entrance Keypad 17
The Report / Receipt Printer (Optional) 25
