4. Harness Application
4.1. List of Main Wire Harness ：
Interface Used Voltage
Description
Harness
JPSTD
24V DC Power & *Data Comm. 55cm WEL-RCC24
JPSTD
24V DC
Power & *Data Comm. 75cm WEL-RCC50
JPSTD
24V DC
Power & *Data Comm. 95cm WEL-RCC49
MDB
20 - 45V DC
Power & *Data Comm. 57cm WEL-RCC23
MDB
20 - 45V DC
Power & *Data Comm. 77cm WEL-RCC51
MDB 20 - 45V DC
Power & *Data Comm. 97cm WEL-RCC47
Power Saving 10 - 45V DC Power & *Data Comm. 97cm
3-CA-RCC71-01
MDB &
MDB Peri
p
heral
24V AC Power & *Data Comm. 97cm WEL-RCC72
Executive 24V AC Power & *Data Comm. 97cm
WEL-RCC54
-
- Download Box Cable (Optional) WEL-RCC42
Warning!! Do not plug both MDB and Executive connecter to VMC board
simultaneously!! It may cause damage of VMC board.
4.2. List of Wire Harness for ICT Bill Acceptor ：
Interface ICT Bill Acceptor Harness
JPSTD
NV Series
WEL-RCC31 +WEL-RCC32
WEL-RCC48
MDB Bill Acceptor WEL-RCC48 +WEL-RCC46
MDB
NV Series
WEL-RCC67 +WEL-RCC68
MDB Bill Acceptor
WEL-RCC48 +WEL-RCC46
WEL-RCC67
Executive
MDB Bill Acceptor
WEL-RCC72
Please refer to Chapter 3-2 < Set the BA Interface > for setting instruction
