Status & Control
This page provides information on system voltage, system current, alarm status,
output status, and current level by output contact (1 through 6). It also allows
you to manually enable or disable DC power to the each of the output terminals.
The status of any of the four Input Alarms for alarms that have been enabled (see
Alarm Setup page) will be shown on this page. A grey Alarm Input indicator box
shows that the sensor input is ready; a red box indicates that that external sensor
is in an alarm condition.
Enable All Outputs: Pressing this button will enable DC power to all outputs. If
power-on sequencing is enabled on the Device Setup page, the outputs will be
enabled in sequence, instead of enabling them simultaneously.
Disable All Outputs: Pressing this button will disable DC power to all outputs.
Output On/Off Buttons: Pressing these buttons will enable or disable DC power
to individual outputs.
If the COMM port on the PDU is connected to an ICT DIN Power Supply, this page
will also display Power Supply status information including output voltage,
output current, alarm status, battery voltage, battery current, battery
temperature, and LVD status.
Alarm Status
This page displays the status of currently active alarms as well as the alarm
history.
Power Supply
The Power Supply page is only accessible if the COMM port on the PDU is
connected to an ICT DIN Power Supply. This page displays the connection status
of ICT DIN Power supply and allows you to configure the power supply settings.
Power Supply Info
Model: Displays the model number of the ICT DIN Power Supply
Battery Charge Current Limit: Displays the maximum battery charge current
that can be provided through the battery terminals of the power supply. This
threshold is set using the selector dial on the ICT DIN Power supply.
Connection Status: Displays the status of the data connection between the
PDU and power supply. “OK” will be shown if the connection is good, “NOT
CONNECTED” will be shown if the data cable is not installed correctly.
